General
Platform Technology
Intel vPro Enterprise
Type
Workstation
Bundled Services
1 Year Lenovo Premier Support
Product Form Factor
MT
Built-in Devices
Speaker
Embedded Security
Discrete Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Core i7 (14th Gen) i7-14700
Clock Speed
2.1 GHz (P-core) / 1.5 GHz (E-core)
Max Turbo Speed
5.4 GHz (P-core) / 4.2 GHz (E-core)
Number of Cores
20-core
CPU Qty
1
Max CPU Qty
1
CPU Socket
FCLGA1700 Socket
Chipset Type
Intel W680
Cache Memory
Installed Size
33 MB
Cache Per Processor
33 MB
RAM
Installed Size
16 GB (installed) / 128 GB (max)
Technology
DDR5 SDRAM - non-ECC
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Form Factor
SO-DIMM 262-pin
Slots
4 (Total) / 3 (empty)
Features
Dual channel memory architecture
Configuration Features
1 x 16 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 512 GB
Interface Type
PCI Express 4.0 x4
Features
TCG Opal Encryption, NVM Express (NVMe), Performance
Storage Controller
Type
1 x SATA
Controller Interface Type
SATA 6Gb/s
Storage Controller (2nd)
Type
1 x NVMe
Controller Interface Type
PCI Express
RAID Level
RAID 0, RAID 1
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
Intel UHD Graphics 770
Video Interfaces
DisplayPort
Audio Output
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
Lenovo Traditional Keyboard
Interface
USB
Localization & Layout
UK
Mouse
Mouse Name
Lenovo Calliope Mouse
Interface
USB
Networking
Interface (Bus) Type
M.2 Card
Ethernet Ports
1 x 2.5 Gigabit Ethernet, 1 x Gigabit Ethernet
Ethernet Controller
Intel I225-LM, I210-AT
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet
Features
Wake on LAN (WoL), dual stream (2x2), Intel Active Management Technology (AMT) 16
Expansion / Connectivity
Slots
1 (total) / 1 (free) x PCIe 4.0 x16 (75W max power) ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 (x4 mode) ¦ 1 (total) / 1 (free) x M.2 Card (for WLAN) ¦ 2 (total) / 1 (free) x M.2 Card (for SSD)
Interfaces
5 x USB 3.2 Gen 2 (1 front, 4 rear) ¦ 2 x Thunderbolt 4 (2 in front) ¦ 1 x LAN (2.5Gigabit Ethernet) (1 rear) ¦ 1 x LAN (Gigabit Ethernet) (1 rear) ¦ 1 x headphones/microphone (1 in front) ¦ 3 x DisplayPort 1.2 (3 rear)
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), chassis intrusion switch
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, FIPS 140-2, TCG Certified, TCO Certified 9.0
Manufacturer Selling Program
Lenovo TopSeller
Power
Device Type
Power adapter
Voltage Required
AC 100-240 V (50/60 Hz)
Power Provided
230 Watt
Efficiency
90%
Operating System / Software
OS Provided
Windows 11 Pro English
Sustainability Information
EPEAT Compliant
EPEAT Gold
ENERGY STAR Certified
Yes
ENERGY STAR Version
8.0
Carbon Footprint
1080 kg carbon emissions
Total CF/unit Standard Deviation (kg CO2e)
403
PAIA Version
1.3.2
Manufacturer Warranty
Service & Support
Base warranty - 3 years - on-site ¦ Extended warranty - 1 year - on-site - response time: next business day
Dimensions & Weight
Width
8.7 cm
Depth
22.3 cm
Height
20.2 cm
Weight
3.6 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 80%
