General
Product Type
OLED TV - Smart TV
Energy Class
Class E
Energy Class (HDR)
Class G
Power Consumption SDR (On mode)
121 kWh/1000h
Power Consumption HDR (On mode)
142 kWh/1000h
Diagonal Class
77"
Diagonal Size
76.8"
Commercial Use
Yes - digital signage
Series
A80L Series
Model Year
2023
Platform
Google TV
Operating System
Android TV 10
HDR Capable
Yes
HDR Format
HDR10, Dolby Vision
HDR Technology
Hybrid Log-Gamma (HLG), XR HDR Remaster
Video Processor
Cognitive XR
TV Tuner
1x analogue, 2x digital
TV Tuner Presence
Yes
Sensors
Light sensor
Video Interface
Composite, HDMI
HDMI Ports Qty
4 ports
Modes
Game mode, Film Mode, Sports mode, Cinema mode, photo mode, Demo Mode, Standard mode, power saving mode, Music mode, Vivid mode, Graphics mode, auto picture mode, Custom mode, Auto Low Latency Mode (ALLM), Calibrated mode, Dolby Vision bright mode, Dolby Vision dark mode, Dolby Vision vivid mode, Auto Genre Picture Mode
Picture Enhancements
CineMotion, IMAX Enhanced, Netflix Calibrated Mode, XR 4K upscaling, OLED XR Contrast Pro, Auto HDR Tone Mapping, XR Clear Image, BRAVIA CORE calibrated
Design
Metal Flush Surface design
Dimensions
Without stand
Width
172.2 cm
Depth
5.4 cm
Height
99.8 cm
Weight
34.8 kg
Enclosure Colour
Titanium black
Display
Resolution
3840 x 2160
Display Format
4K UHD (2160p)
Image Aspect Ratio
16:9
Frame Rate & Enhancement Technology
120 Hz Native Refresh Rate, 100 Hz Native Refresh Rate, Variable Refresh Rate (VRR), XR OLED Motion
24p Technology
24p True Cinema
LCD Backlight Technology
Frame blinking
Viewing Angle
178 degrees
Viewing Angle (Vertical)
178 degrees
Display Menu Language
Multilingual
Features
Audio Description (AD), PhotoTV HD, Face Area Detection, Cinema Drive, X-Protection PRO, sleep timer, Chromecast built-in, CalMAN auto calibration support, Apple AirPlay support, screen reader, text magnification, USB hard disk recording, XR Triluminos Pro Display, BRAVIA CAM support, ECO Dashboard
Stands & Mounts
Stand
Included
Stand Design
Tabletop
Stand Colour
Dark silver
Stand Features
3-way position, aluminium slim wedged stand
Flat Panel Mount Interface
300 x 300 mm
VESA Compatibility
Yes
TV Tuner
Conditional Access
Common Interface Plus (CI+) slot
Reception System
PAL, NTSC, SECAM
Digital TV Tuner
Digital TV Tuner
DVB-C, DVB-S, DVB-S2, DVB-T, DVB-T2
HDTV Tuner
Yes
Video Features
Analogue Video Input Signals
PAL, SECAM, NTSC 3.58, NTSC4.43
Input Video Formats
480p, 576p, 1080/24p, 1080/60i, 720/60p, 1080/50i, 720/50p, 1080/50p, 1080/60p, 1080/30p, 2160/24p, 2160/25p, 2160/30p, 720/24p, 720/30p, 2160/50p, 2160/60p
Teletext
Yes
Teletext Memory
1000 pages
Electronic Programme Guide
Digital EPG
Parental Channel Lock
Yes
Closed Caption Capability
Yes
Media Player
Supported Video Formats
MPEG-1, MPEG-2, MPEG-4, Motion-JPEG, Xvid, WMV, ASF, AVI, MKV, MOV, AVCHD, TS, AVC, 3GPP, PS, VC-1, WebM, HEVC, VP9, VP8, XAVCS, HDV
Supported Audio Formats
MP3, WMA, WAV, AAC, FLAC (Free Lossless Audio Codec), LPCM, ASF, MP4, OGG, AC4
Supported Pictures Formats
RAW, JPEG
USB Port
Yes
USB Ports Qty
2
Configuration
32 GB
Remote Control
Type
Remote control
Remote Control Model
Sony RMF-TX810U+RMT-TX450E
Battery Included
Yes
Features
Voice control, talkback
Audio System
Digital Audio Format
DTS digital output, Dolby Atmos, Dolby Audio
Surround Mode
Yes
Sound Effects
S-FORCE Front Surround Sound, DTS Digital Surround
Speaker System
3 speakers, 2 subwoofers
Output Power / Total
60 Watt
Features
Down-firing Speaker, S-Master Digital Amplifier, Audio Return Channel (ARC), auto mute, Clear Phase Speaker, Advanced Auto Volume, Acoustic Surface Audio+ technology, Enhanced Audio Return Channel (eARC), Voice Zoom 2, Room Compensation, Vertical Surround Engine, User Position Compensation, Acoustic Center Sync, built-in microphone switch
Speakers
3 x speaker ¦ 2 x subwoofer
Network & Internet Multimedia
Functionality
WEB browsing, Internet video playback
Connectivity
Wi-Fi, LAN, Bluetooth
LAN Protocol
Ethernet
Wi-Fi Protocol
802.11b, 802.11g, 802.11n, 802.11a, 802.11ac
Bluetooth Version
Bluetooth 4.2
Connect & Share
Wi-Fi Direct, Screen Mirroring, Wi-Fi Miracast, Bluetooth Human Interface Device (HID), Home Network Client, Home Network Renderer
Internet Streaming Services
Voice Search, Bravia Core
Supported Consumer Electronics Control (CEC)
BRAVIA Sync Function
Application Store
Google Play
Connections
Connector Type
Composite video input - side ¦ 4 x HDMI input - side ¦ Audio input - side ¦ Digital audio output - side ¦ LAN - side ¦ 2 x USB - side
Internet of Things (IoT)
Internet of Things (IoT) Compatible
Yes
Platform
Apple HomeKit
Miscellaneous
Compliant Standards
HDCP 2.3, Mercury-free
Power
Power Device
Power supply
Input Voltage
AC 220-240 V (50 Hz)
Power Consumption Stand by
0.5 Watt
Auto On/Off
Yes
Features
On/off timer
Manufacturer Warranty
Service & Support
Limited warranty - advanced exchange programme - 3 years
Bundled Services
3 years PrimeSupport
Dimensions & Weight Details
Dimensions & Weight Details
Panel without stand - 172.2 cm x 5.4 cm x 99.8 cm x 34.8 kg ¦ Panel with stand - 172.2 cm x 38.9 cm x 102.7 cm x 36 kg ¦ Panel with stand and soundbar - 172.2 cm x 38.5 cm x 106.6 cm x 36 kg
Dimensions & Weight (Shipping)
Width (Shipping)
185.8 cm
Depth (Shipping)
18.8 cm
Height (Shipping)
113 cm
Weight (Shipping)
47 kg
