General
Type
Document scanner - desktop
Interface Type
USB 3.0, LAN, Wi-Fi(n), USB 2.0 (Host)
Additional Functions
Scan to FTP, scan to SharePoint, scan to email, scan to image, scan to network folder, scan to PC
Max Supported Document Size
215.9 x 355.6 mm
Scanner
Input Type
Colour
Grayscale Depth
8-bit (256 colours)
Colour Depth
48-bit colour
Colour Depth (External)
24-bit (16.7 million colours)
Optical Resolution
600 dpi x 600 dpi
Interpolated Resolution
1200 dpi x 1200 dpi
Automatic Duplexing
Yes
Scanning Sensor Type
Dual CIS
Bulb / Light Source Type
LED
Max Document Scan Speed B/W
40 ppm
Max Document Scan Speed Colour
40 ppm
Duty Cycle
6000 scans per day
Scanner Speed Details
40 ppm - black & white - A4 ¦ 40 ppm - colour - A4 ¦ 80 ipm - duplex - black & white ¦ 80 ipm - duplex - colour
Scanner Features
Scan to portable USB drive, Automatic Separation, automatic page size detection, blank page skipping, Auto Deskew, Remove Background, Long Document Scanning, One-Touch button, auto image rotation, 10.9 cm colour touch screen
Compliant Standards
TWAIN, ISIS, WIA, SANE
Media Handling
Max Document Size
215.9 mm x 355.6 mm
Supported Document Type
Plain paper, business card, plastic card
Supported Document Size Details
ADF - up to 215.9 x 355.6 mm
Document Feeder Type
Automatic
Document Storage Capacity
80 sheets
Expansion / Connectivity
Interfaces
USB 2.0 (Host) - Type A ¦ USB 3.0 ¦ LAN
Miscellaneous
Cables Included
1 x USB cable
Compliant Standards
GS, WHQL, RoHS, WPA3
Power
Power Device
Internal power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Power Consumption Operational (Standby)
26 Watt
Power Consumption Stand by
8.6 Watt
Power Consumption Sleep
1.7 Watt
Software / System Requirements
Software Included
BRAdmin Professional, Kofax Power PDF Standard v3
OS Required
Microsoft Windows 7 (32/64 bits) SP1, Microsoft Windows Server 2012, Windows 8.1 (32/64 bits), Microsoft Windows Server 2012 R2, Windows 10 (32/64 bits), Microsoft Windows Server 2016, Microsoft Windows Server 2019, Apple macOS 10.14.x or later
Dimensions & Weight
Width
29.95 cm
Depth
19.05 cm
Height
21.59 cm
Weight
2.75 kg
Dimensions & Weight (Shipping)
Shipping Width
39.1 cm
Shipping Depth
24.3 cm
Shipping Height
32 cm
Shipping Weight
3.46 kg
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Environmental Parameters
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 80%
Sound Emission
59 dB
