Fast and productive¦Reduce the time a customer spends waiting in line and how long it takes to process paperwork. Total cost of ownership is also minimised with a high ribbon yield of 10 million characters.¦Optional extras¦Get more from your passbook printer with additional features that include an MICR/MSRW head plus a 3-port built-in USB hub for easy connectivity.
Print SpeedUp to 480 char/sec - high speed draft ¦ Up to 360 char/sec - draft ¦ Up to 120 char/sec - letter ¦ Up to 144 char/sec - letter ¦ Up to 540 char/sec - draft ¦ Up to 432 char/sec - draft ¦ Up to 576 char/sec - high speed draft
Max Resolution (B&W)360 x 360 dpi
InterfaceParallel, USB 2.0, serial
Language SimulationEPSON ESC/P 2, IBM PPDS, Olivetti PR2
BarcodesIndustrial 2 of 5, Code 39, NW-7, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, Code 128, Interleaved 2 of 5, Postnet
Media TypePlain paper, passbook
Scanner TypeDocument scanner
Scan Depth / Resolution24-bit (16.7 million colours) / 600 x 600 dpi
System RequirementsMicrosoft Windows 7, Microsoft Windows Vista, Microsoft Windows XP (32/64 bits), Windows 8
Print SpeedUp to 480 char/sec - high speed draft - 10 cpi ¦ Up to 360 char/sec - draft - 10 cpi ¦ Up to 120 char/sec - letter - 10 cpi ¦ Up to 144 char/sec - letter - 12 cpi ¦ Up to 540 char/sec - draft - 15 cpi ¦ Up to 432 char/sec - draft - 12 cpi ¦ Up to 576 char/sec - high speed draft - 12 cpi
Connectivity TechnologyWired
InterfaceParallel, USB 2.0, serial
Max Resolution (B&W)360 x 360 dpi
Language SimulationEPSON ESC/P 2, IBM PPDS, Olivetti PR2
BarcodesIndustrial 2 of 5, Code 39, NW-7, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, Code 128, Interleaved 2 of 5, Postnet
Media Handling
Media TypePlain paper, passbook
Max Media Size245 x 297 mm
Min Media Size (Custom)65 mm x 67 mm
Max Media Size (Custom)245 mm x 297 mm
Media Sizes65 x 67 mm, 245 x 297 mm
Media Weight34 g/m² - 157 g/m²
Max Sheets in Multi-Part Form7
Scanner
TypeDocument scanner
Grayscale Depth8-bit (256 grey levels)
Colour Depth24-bit (16.7 million colours)
Optical / Interpolated Resolution600 x 600 dpi
Expansion / Connectivity
Connections1 x parallel ¦ 1 x RS-232 - 9 pin D-Sub (DB-9) ¦ 1 x USB 2.0 - 4 pin USB Type B
Miscellaneous
Consumables Included1 x ribbon (black)
MTBF10,000 hour(s)
Compatible with Windows 7"Compatible with Windows 7" software and devices carry Microsoft’s assurance that these products have passed tests for compatibility and reliability with 32-bit and 64-bit Windows 7.
Power
Power DevicePower supply - internal
Frequency Required50/60 Hz
Power Consumption Operational60 Watt
Power Consumption Sleep8 Watt
Software / System Requirements
OS RequiredMicrosoft Windows 7, Microsoft Windows Vista, Microsoft Windows XP (32/64 bits), Windows 8
