General
Device Type
Network surveillance camera
Audio Support
Yes: two-way audio capability
Audio Formats
LPCM, AAC-LC, ADPCM, G.711, G.726, OPUS, PCM
Form Factor
Box
Camera Mount Type
Wall mount
Connectivity Technology
Wired
Width
15.9 cm
Depth
40.4 cm
Height
18.2 cm
Weight
4.4 kg
Camera
Type
Colour - Day&Night - fixed - outdoor - weatherproof
Digital Video Format
H.264B, H.264H, H.264M, H.265, MJPEG, MPEG-4 AVC, MPEG-4 Part 10, HEVC, MPEG-H Part 2
Max Digital Video Resolution
2688 x 1512
Motion Detection
Yes
Exposure Range
1 sec - 1/47500 sec
Minimum Illumination
0.05 lux - colour - F1.5 - 50 IRE ¦ 0.01 lux - B&W - F1.5 - 50 IRE ¦ 0 lux - IR
Infrared LEDs
Yes
Infrared Distance
50 m
Video Capture
2688 x 1512 @ 60 fps
RAM
2 GB
Flash Memory
8 GB
Features
Window wiper, Lightfinder 2.0 technology, Forensic WDR, electronic image stabilisation, Zipstream technology, signed firmware, secure boot, remote focus, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, infrared-cut filter, Variable Bitrate (VBR), Adaptive Bitrate (ABR), Constant Bitrate (CBR), multi-streaming, brightness control, saturation control, contrast control, white balance, exposure zone, exposure control, Defog, distortion correction function, 180° image rotation, 270° image rotation, 90° image rotation, Corridor mode, image mirror, image overlay, text overlay, polygon privacy mask, digital PTZ function, Pelco Protocol, Audio Noise Reduction, password protection, IP address filtering, brute force delay protection, TPM 2.0 module, heater, Audio Detection, notification picture to FTP, notification picture to E-mail, Remote Back Focus, Pixel Counter Support, human detection, Vehicle Detection, Line Crossing Detection
Image Sensor
Type
4 MP PS CMOS 1/1.8"
Lens Construction
Type
CS-mount - motorized zoom
Optical Zoom
2.5 x
Focal Length
3.9 mm - 10 mm
Lens Iris
(P-Iris)
Focus Adjustment
Automatic
Min Focus Distance
50 cm
Horizontal Field of View (degree)
47 - 113
Vertical Field of View (degree)
27 - 60
Interfaces
Network Interface
Ethernet 10Base-T/100Base-TX/1000Base-T
Network Protocols
HTTPS, EAP, TLS, IPv4, IPv6, USGv6, HTTP, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, RTSP, RTP, SRTP, TCP/IP, UDP/IP, IGMP, IGMPv2, IGMPv3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT
Control Interface
RS-422, RS-485
Expansion / Connectivity
Ports
LAN/power - RJ-45 ¦ Audio line out - 3.5 mm jack ¦ Audio line-in/microphone - 3.5 mm jack ¦ Serial RS-485/RS-422 - terminal block
Supported Memory Cards
SD Memory Card, SDXC Memory Card, SDHC Memory Card
Miscellaneous
Included Accessories
Sunshield, wall mount kit, connector kit, Resistorx T20 tool
Compliant Standards
IK10, NEMA TS-2, IEEE 802.1x, IK08, PVC-free, BFR-free, IEEE 802.3af, IEEE 802.3at, CISPR 24, CISPR 35, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, CAN ICES-3(B)/NMB3(B), EN 50121-4, IEC 62236-4, KS C 9832 Class A, KS C 9815, KS C 9835, KS C 9547, AS/NZS CISPR 32 Class A, RCM, VCCI Class A, IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, IEC 62471, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 60529 IP67, IEC/EN 62262 IK10, NEMA250 Type 4X, ISO 21207 method B, NIST SP500-267
Colour
White
Power
Power Requirements
DC 10 - 28 V / PoE Plus Class 4
Software / System Requirements
Software Included
Windows decoder 1-user licence
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
60 °C
Relative Humidity (operating)
10 - 100% RH (condensing)
