AXIS

AXIS Q1656 DAY/NIGHT FIXED BOX CAMERA

Name: AXIS Q1656 DAY/NIGHT FIXED BOX CAMERA
Brand: AXIS
SKU: 1TSECSPD-003866
Price: 1438.57 GBP
Availability: OutOfStock

SKU

1TSECSPD-003866

Manufacture#: 02164-001

Be the first to review this product

£1198.81

£1438.57 inc VAT

Checking delivery…

Product details

Network surveillance camera
box
colour (Day&Night)
4 MP

View full product specification

Notify me when this product is in stock

Payment options available at checkout

Compare product

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Overview

Main features

AXIS Q1656
Network surveillance camera
box
colour (Day&Night)
4 MP
2688 x 1512
i-CS-mount
auto iris
vari-focal
audio
GbE
H.264B, H.264H, H.264M, H.265, MJPEG, MPEG-4 AVC, MPEG-4 Part 10, HEVC, MPEG-H Part 2
DC 10
28 V / PoE Plus Class 3

Overview

With premium Q-line functionality and exceptional video quality even in poor light, AXIS Q1656 is based on the latest Axis system-on-chip (SoC) and offers support for powerful analytics based on deep learning on the edge.

Specification

Product Description AXIS Q1656 - network surveillance camera - box

Device Type Network surveillance camera - fixed - box

Audio Yes: two-way audio capability

Dimensions (WxDxH) 8 cm x 21.4 cm x 6.8 cm

Weight 790 g

Colour Black

Connectivity Technology Wired

Camera Colour - Day&Night

Optical Zoom 2.9 x

Max Resolution 2688 x 1512

Frame Rate (max) 60 frames per second

Motion Detection Yes

Optical Sensor Type RGB CMOS - 1/1.8" - 4 MP

Focal Length Control Vari-focal

Focal Length 3.9 mm - 10 mm

Lens Mounting I-CS-mount

Focus Adjustment (min distance 50 cm)

Lens Iris F/1.5 - auto iris (P-Iris)

Interfaces Ethernet 10Base-T/100Base-TX/1000Base-T

Control Interface RS-422, RS-485

Voltage DC 10 - 28 V / PoE Plus Class 3

Features Lightfinder 2.0 technology, Forensic WDR, electronic image stabilisation, Zipstream technology, signed firmware, secure boot, remote focus, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, infrared-cut filter, Variable Bitrate (VBR), Adaptive Bitrate (ABR), Constant Bitrate (CBR), multi-streaming, brightness control, saturation control, contrast control, white balance, exposure zone, exposure control, Defog, distortion correction function, Corridor mode, 180° image rotation, 270° image rotation, 90° image rotation, polygon privacy mask, image mirror, image overlay, text overlay, password protection, digital PTZ function, Pelco Protocol, Audio Noise Reduction, heater, IP address filtering, brute force delay protection, TPM 2.0 module, Remote Back Focus, Audio Detection, notification picture to FTP, notification picture to E-mail, Line Crossing Detection, Axis Edge Vault

Manufacturer Warranty 5-year warranty

Environmental Parameters (operating) -20 °C - 60 °C; 10 - 85% (non-condensing) relative humidity

General

Device Type Network surveillance camera

Audio Support Yes: two-way audio capability

Audio Formats LPCM, AAC-LC, ADPCM, G.711, G.726, OPUS, PCM

Form Factor Box

Connectivity Technology Wired

Width 8 cm

Depth 21.4 cm

Height 6.8 cm

Weight 790 g

Camera

Type Colour - Day&Night - fixed

Digital Video Format H.264B, H.264H, H.264M, H.265, MJPEG, MPEG-4 AVC, MPEG-4 Part 10, HEVC, MPEG-H Part 2

Max Digital Video Resolution 2688 x 1512

Motion Detection Yes

Exposure Range 1 sec - 1/47500 sec

Digital Video Capture Resolution 2688 x 1512, 160 x 90, 2016 x 1512, 160 x 120

Frame Rate (max) 60 frames per second

RAM 2 GB

Flash Memory 8 GB

Image Sensor

Type 4 MP RGB CMOS 1/1.8"

Lens Construction

Type I-CS-mount - vari-focal

Optical Zoom 2.9 x

Focal Length 3.9 mm - 10 mm

Lens Iris F/1.5 auto iris (P-Iris)

Min Focus Distance 50 cm

Horizontal Field of View (degree) 47 - 120

Vertical Field of View (degree) 27 - 63

Interfaces

Network Interface Ethernet 10Base-T/100Base-TX/1000Base-T

Network Protocols HTTPS, EAP, TLS, IPv4, IPv6, USGv6, HTTP, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, RTSP, RTP, SRTP, TCP/IP, UDP/IP, IGMP, IGMPv2, IGMPv3, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, MQTT

Control Interface RS-422, RS-485

Expansion / Connectivity

Ports LAN/power - RJ-45 ¦ Audio line out - 3.5 mm jack ¦ Audio line-in/microphone - 3.5 mm jack ¦ Serial RS-485/RS-422 - terminal block

Supported Memory Cards SD Memory Card, SDXC Memory Card, SDHC Memory Card

Miscellaneous

Included Accessories Resistorx L-key, stand, drill hole template, connector kit

Compliant Standards NEMA TS-2, IEEE 802.1x, IK08, PVC-free, BFR-free, IEEE 802.3af, IEEE 802.3at, CISPR 24, CISPR 35, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, CAN ICES-3(B)/NMB3(B), EN 50121-4, IEC 62236-4, KS C 9832 Class A, KS C 9815, KS C 9835, KS C 9547, AS/NZS CISPR 32 Class A, RCM, VCCI Class A, IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, IEC 62471, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, IEC/EN 60529 IP67, IEC/EN 62262 IK10, NEMA250 Type 4X, ISO 21207 method B, NIST SP500-267

Colour Black

Power

Power Requirements DC 10 - 28 V / PoE Plus Class 3

Power Device 5.1 Watt

Software / System Requirements

Software Included Windows decoder 1-user licence

Manufacturer Warranty

Service & Support Limited warranty - 5 years

Environmental Parameters

Min Operating Temperature -20 °C

Max Operating Temperature 60 °C

Relative Humidity (operating) 10 - 85% (non-condensing)
