Name: PM23C FT ROW ETH LG R+L HGR+RTCTT300EU IN
Brand: HONEYWELL
SKU: 1TPRNRPR-006353
Price: 1810.15 GBP
Availability: OutOfStock

Overview

Main features

Honeywell PM23c
Label printer
thermal transfer
Roll (6.8 cm)
300 dpi
up to 300 mm/sec
USB 2.0, LAN, serial, USB host
rewinder

Overview

The PM23c mid-range industrial printer features a two-inch print width and a compact footprint, ideal for demanding applications in transportation, manufacturing, retail, distribution center and warehouse environments.

Specification

Product Description Honeywell PM23c - label printer - B/W - thermal transfer

Printer Type Label printer - thermal transfer - B/W

Weight 9.5 kg

Localisation Europe

Max Media Size Roll (6.8 cm)

Min Media Size (Custom) 19 mm

Max Media Size (Custom) 68 mm

Print Speed Up to 300 mm/sec - max speed

Max Resolution (B&W) 300 dpi

Interface USB 2.0, LAN, serial, USB host

RAM Installed (Max) 128 MB SDRAM

Flash Memory Installed (Max) 128 MB

Language Simulation ZPL, Intermec Printer Language (IPL), Intermec Fingerprint, Intermec Direct Protocol, DSim (Datamax Interpreter), ZSim, Extensible Mark-up Language (XML), DPL

Barcodes EAN/JAN, Code 93, Matrix 2 of 5, Industrial 2 of 5, Code 39, Code 49, ISBT 128, QR code, MaxiCode, Aztec code, MicroPDF417, Codabar, Code 128, Code 11, Code 16K, UPC, Interleaved 2 of 5, Postnet, PDF417, MSI-Plessey, Data Matrix, PLANET, Plessey, Standard 2 of 5, Grid Matrix Code

Media Type Labels, linerless labels, fanfold paper, tag stock

Features Rewinder, realtime clock

Networking Print server

Dimensions (WxDxH) 20.55 cm x 43.184 cm x 18.1 cm

General

Printer Type Label printer - thermal transfer - monochrome

Localisation Europe

Printer

Print Speed Up to 300 mm/sec - max speed - 300 dpi

Built-in Devices Status LCD

Connectivity Technology Wired

Interface USB 2.0, LAN, serial, USB host

Max Resolution (B&W) 300 dpi

Language Simulation ZPL, Intermec Printer Language (IPL), Intermec Fingerprint, Intermec Direct Protocol, DSim (Datamax Interpreter), ZSim, Extensible Mark-up Language (XML), DPL

Features Rewinder, realtime clock

Barcodes EAN/JAN, Code 93, Matrix 2 of 5, Industrial 2 of 5, Code 39, Code 49, ISBT 128, QR code, MaxiCode, Aztec code, MicroPDF417, Codabar, Code 128, Code 11, Code 16K, UPC, Interleaved 2 of 5, Postnet, PDF417, MSI-Plessey, Data Matrix, PLANET, Plessey, Standard 2 of 5, Grid Matrix Code

RAM

RAM Installed (Max) 128 MB

Technology / Form Factor SDRAM

Flash Memory

Flash Memory 128 MB

Media Handling

Media Type Labels, linerless labels, fanfold paper, tag stock

Max Media Size Roll (6.8 cm)

Min Media Size (Custom) 19 mm

Max Media Size (Custom) 68 mm

Media Sizes Roll (1.9 - 6.8 cm)

Max Printing Width 56 mm

Roll Maximum Outer Diameter 61 mm

Roll Core Diameter 76 mm, 38 mm

Media Feeders 1 x manual - 1 roll

Networking

Networking Print server

Remote Management Protocol SNMP 1, SNMP 3, SNMP 2c

Expansion / Connectivity

Connections 1 x LAN - RJ-45 ¦ 1 x RS-232 - 9 pin D-Sub (DB-9) ¦ 1 x USB 2.0 - 4 pin USB Type B ¦ 1 x USB host - 4 pin USB Type A

Miscellaneous

Compliant Standards FCC Class A certified, UL, cUL, EN55022 Class A, CCC, RoHS

Power

Power Device Power supply - internal

Frequency Required 50/60 Hz

Power Consumption Operational 300 Watt

Power Consumption Stand by 9 Watt

Environmental Parameters

Min Operating Temperature 5 °C

Max Operating Temperature 40 °C

Humidity Range Operating 20 - 80% (non-condensing)

Dimensions & Weight

Width 20.55 cm

Depth 43.184 cm

Height 18.1 cm

Weight 9.5 kg
