General
Type
Server
Recommended Use
Small business, corporate business
Product Form Factor
Rack-mountable - 2U
Server Scalability
2-way
Hot-Swap Bays Qty
8
Localisation
Region: Europe
Processor / Chipset
CPU
AMD Opteron 6344
Clock Speed
2.6 GHz
Max Turbo Speed
3.2 GHz
Number of Cores
12-core
CPU Qty
2
Max CPU Qty
2
CPU Upgradability
Upgradable
Chipset Type
AMD SR5690/SP5100
Cache Memory
Installed Size
L3 Cache - 32 MB
Cache Per Processor
16 MB
RAM
Installed Size
32 GB / 384 GB (max)
Technology
DDR3 SDRAM
Effective Memory Speed
1333 MHz
Rated Memory Speed
1333 MHz
Memory Specification Compliance
PC3-10600
Form Factor
DIMM 240-pin
Slots
24 (Total) / 20 (empty)
Features
Registered
Configuration Features
4 x 8 GB
RAM Supported
PC3-12800 - 384 GB registered ¦ PC3-10600 - 768 GB Load-Reduced ¦ PC3-10600 - 384 GB - low voltage - registered
Storage Controller
Type
1 x RAID - integrated - PCIe 2.0 x4
Controller Interface Type
SATA 3Gb/s / SAS 6Gb/s
Storage Controller Name
Smart Array P420i with 1GB FBWC
Channel Qty
8
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10, RAID 50
Buffer Size
1 GB
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Type
Integrated
Graphics Processor
Matrox G200
Video Interfaces
VGA
Networking
Type
Integrated
Interface (Bus) Type
PCI Express x4
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
HP 331FLR
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3ad (LACP)
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
24 (total) / 20 (free) x DIMM 240-pin ¦ 2 (total) / 0 (free) x CPU ¦ 1 (total) / 1 (free) x PCIe 2.0 x16 - full-length, full-height (x8 mode) ¦ 1 (total) / 1 (free) x PCIe 2.0 x8 - half-length, full-height (x8 mode) ¦ 1 (total) / 1 (free) x PCIe 2.0 x8 - half-length, full-height (x4 mode) ¦ 1 (total) / 1 (free) x SD card
Interfaces
1 x serial ¦ 2 x VGA (1 front, 1 rear) ¦ 4 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 8 x USB 2.0 (2 front, 4 rear, 2 internal)
Miscellaneous
Included Accessories
HP Ball Bearing Rail Kit, cable management arm
Features
Administrator password, power-on password, serial port I/O control, 80 PLUS Platinum Plus
Compliant Standards
ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, BSMI CNS 13438
Power
Device Type
Power supply - hot-plug
Power Redundancy
Yes
Power Redundancy Scheme
1+1
Installed Qty
2
Max Supported Qty
2
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
750 Watt
80 PLUS Certification
80 PLUS Platinum
Efficiency
94%
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris, Citrix XenServer
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Width
44.55 cm
Depth
69.85 cm
Height
8.73 cm
Weight
18.59 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
