General
Platform Technology
Intel vPro Platform
Type
Point of sale terminal
Product Form Factor
Small form factor
Built-in Devices
Speaker
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Core i7 (8th Gen) 8700
Clock Speed
3.2 GHz
Max Turbo Speed
4.6 GHz
CPU Qty
1
Max CPU Qty
1
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2
Cache Memory
Installed Size
12 MB
Cache Per Processor
12 MB
RAM
Installed Size
16 GB / 64 GB (max)
Technology
DDR4 SDRAM
Effective Memory Speed
2666 MHz
Rated Memory Speed
2666 MHz
Form Factor
DIMM 288-pin
Slots
4 (Total) / 2 (empty)
Features
Unbuffered
Configuration Features
2 x 8 GB
Hard Drive
Type
SSD - 2.5"
Capacity
1 x 256 GB
Interface Type
SATA 6Gb/s
Features
Triple-level cell (TLC)
Storage Controller
Type
1 x SATA
Controller Interface Type
SATA 6Gb/s / SATA 3Gb/s
Optical Storage
Type
DVD-Writer - SATA
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
Intel UHD Graphics 630 Dynamic Video Memory Technology
Video Interfaces
DisplayPort
HDCP Compatible
Yes
Audio Output
Sound Output Mode
Stereo
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Input Device
Type
Keyboard
Keyboard
Keyboard Name
HP Business Slim Keyboard
Localization & Layout
UK
Networking
Ethernet Controller
Intel I219-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel Dual Band Wireless-AC 9260
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), ACPI support, PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3x, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11n, IEEE 802.3az, IEEE 802.11ac, Bluetooth 5.0
Expansion / Connectivity
Bays
2 (total) / 1 (free) x internal 3.5" ¦ 1 (total) / 0 (free) x external 5.25"
Slots
2 (total) / 2 (free) x PCIe x1 - full-height ¦ 1 (total) / 1 (free) x PCIe x16 - half-height ¦ 1 (total) / 1 (free) x PCIe x16 - half-height (x4 mode) ¦ 2 (total) / 1 (free) x M.2 Card
Interfaces
2 x USB 2.0 ¦ 5 x USB 3.1 Gen 1 (2 front, 3 rear) (one of them is charging) ¦ 1 x PS/2 keyboard / mouse ¦ 1 x DisplayPort ¦ 1 x audio line-in/microphone ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x PoweredUSB (24 V)
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, WEEE
Power
Device Type
Power supply
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
250 Watt
Efficiency
90%
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 10 Pro 64-bit Edition English
Software
HP Recovery Manager, HP Support Assistant, HP ePrint, HP Hotkey Support, HP Secure Erase, HP Drive Packs (free download), HP Client Catalog, HP BIOS Config Utility, HP JumpStart, HP Noise Cancellation, HP System Software Manager, HP JetAdvantage, HP Wireless Wakeup, HP Sure Click, HP BIOSphere Gen4, HP Manageability & Integration Kit Gen2, HP Client Security Suite Gen4, HP SureStart Gen4, HP Sure Run, HP Sure Recover
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Dimensions & Weight
Width
33.7 cm
Depth
38.4 cm
Height
10 cm
Weight
6.44 kg
Dimensions & Weight (Shipping)
Shipping Width
22.9 cm
Shipping Depth
49.6 cm
Shipping Height
36.1 cm
Shipping Weight
7.26 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 85% (non-condensing)
