General
Type
Server
Product Form Factor
Tower - 4U
Server Scalability
2-way
Hot-Swap Bays Qty
8
Localisation
Region: Europe
Processor / Chipset
CPU
Intel Xeon Gold 5218
Clock Speed
2.3 GHz
Max Turbo Speed
3.9 GHz
Number of Cores
16-core
CPU Qty
1
Max CPU Qty
2
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2
CPU Socket
FCLGA3647 Socket
Chipset Type
Intel C622
Cache Memory
Installed Size
L3 Cache - 22 MB
Cache Per Processor
22 MB
RAM
Installed Size
32 GB / 1.5 TB (max)
Technology
DDR4 SDRAM - Advanced ECC
Effective Memory Speed
2666 MHz
Rated Memory Speed
2933 MHz
Form Factor
DIMM 288-pin
Slots
24 (Total) / 23 (empty)
Features
Registered, Online Spare Memory, slots 13 - 24 are available in two-processor configuration only, HPE SmartMemory
Configuration Features
1 x 32 GB
RAM Supported
3 TB Load-Reduced - ECC ¦ 1.5 TB registered - ECC
Storage Controller
Type
1 x RAID - PCIe 3.0 x8
Controller Interface Type
SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name
HPE Smart Array P408i-a
Channel Qty
8
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60, RAID 1 ADM, RAID 10 ADM
Buffer Size
2 GB
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Video Memory
16 MB
Video Interfaces
VGA
Networking
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
HPE 369i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out Advanced Management (ASIC)
Features
Wake on LAN (WoL), PXE support
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 2 (free) x PCIe 3.0 x8 - full-length, full-height (x4 mode) ¦ 4 (total) / 4 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal) ¦ 2 (total) / 2 (free) x PCIe 3.0 x8 - full-length, full-height
Interfaces
1 x VGA ¦ 1 x serial ¦ 4 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 5 x USB 3.0 (2 front, 2 rear, 1 internal) ¦ 1 x USB 2.0 (1 internal) ¦ 1 x HPE iLO - Type A (1 in front)
Miscellaneous
Included Accessories
6 fan modules
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Compliant Standards
ASHRAE Class A4, ASHRAE Class A3, ACPI 6.1
Power
Device Type
Power supply - hot-plug
Power Redundancy
Yes
Power Redundancy Scheme
1+1
Installed Qty
2
Max Supported Qty
2
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
800 Watt
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Environmental Standards
ENERGY STAR Certified
Yes
ENERGY STAR Version
2.1
Manufacturer Warranty
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight
Width
17.4 cm
Depth
64.8 cm
Height
46.25 cm
Weight
21 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
