General
Platform Technology
Intel vPro Enterprise
Type
Workstation
Bundled Services
1 Year Lenovo Premier Support
Product Form Factor
Mini tower
Built-in Devices
Speaker
Embedded Security
Discrete Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Processor / Chipset
CPU
Intel Core i7 (13th Gen) 13700
Clock Speed
2.1 GHz (P-core) / 1.5 GHz (E-core)
Max Turbo Speed
5.2 GHz (P-core) / 4.1 GHz (E-core)
Number of Cores
16-core
CPU Qty
1
Max CPU Qty
1
CPU Socket
FCLGA1700 Socket
Chipset Type
Intel W680
Cache Memory
Installed Size
30 MB
Cache Per Processor
30 MB
RAM
Installed Size
16 GB / 128 GB (max)
Technology
DDR5 SDRAM - non-ECC
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Form Factor
SO-DIMM 262-pin
Slots
4 (Total) / 2 (empty)
Features
Dual channel memory architecture
Configuration Features
2 x 8 GB
Hard Drive
Type
SSD - M.2 2280
Capacity
1 x 512 GB
Interface Type
PCI Express 4.0 x4
Features
TCG Opal Encryption, NVM Express (NVMe), Performance
Storage Controller
Type
1 x SATA
Controller Interface Type
SATA 6Gb/s
Storage Controller (2nd)
Type
1 x RAID
Controller Interface Type
PCI Express (NVMe)
RAID Level
RAID 0, RAID 1
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Multi-GPU Configuration
1 single GPU card / integrated GPU
Graphics Processor
NVIDIA T1000 / Intel UHD Graphics 770
Video Memory
8 GB GDDR6 SDRAM
Video Interfaces
DisplayPort, Thunderbolt
Audio Output
Compliant Standards
High Definition Audio
Input Device
Type
Mouse, keyboard
Keyboard
Keyboard Name
Lenovo Traditional Keyboard
Interface
USB
Localization & Layout
UK
Mouse
Mouse Name
Lenovo Calliope Mouse
Interface
USB
Networking
Interface (Bus) Type
M.2 Card
Ethernet Ports
1 x 2.5 Gigabit Ethernet, 1 x Gigabit Ethernet
Ethernet Controller
Intel I225-LM, I210-AT
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6E AX 211
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, Bluetooth 5.1, IEEE 802.11ax (Wi-Fi 6E)
Features
Wake on LAN (WoL), dual stream (2x2), Intel Active Management Technology (AMT) 16
Expansion / Connectivity
Slots
1 (total) / 0 (free) x PCIe 4.0 x16 ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 (x4 mode) ¦ 1 (total) / 0 (free) x M.2 Card (for WLAN) ¦ 2 (total) / 1 (free) x M.2 Card (for SSD)
Interfaces
5 x USB 3.2 Gen 2 (1 front, 4 rear) ¦ 2 x Thunderbolt 4 (2 in front) ¦ 1 x LAN (2.5Gigabit Ethernet) (1 rear) ¦ 1 x LAN (Gigabit Ethernet) (1 rear) ¦ 1 x headphones/microphone (1 in front) ¦ 3 x DisplayPort 1.2 (3 rear) ¦ 4 x Mini DisplayPort 1.4
Miscellaneous
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), chassis intrusion switch
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, TCG Certified, MIL-STD-810H, TCO Certified 9.0
Manufacturer Selling Program
TopSeller
Power
Device Type
Power adapter
Voltage Required
AC 100-240 V (50/60 Hz)
Power Provided
230 Watt
Efficiency
90%
Operating System / Software
OS Provided
Windows 11 Pro English
Sustainability Information
EPEAT Compliant
EPEAT Gold
ENERGY STAR Certified
Yes
ENERGY STAR Version
8.0
Manufacturer Warranty
Service & Support
Base warranty - 3 years - on-site ¦ Extended warranty - 1 year - on-site - response time: next business day
Dimensions & Weight
Width
8.7 cm
Depth
22.3 cm
Height
20.2 cm
Weight
3.6 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 80%
