General
Type
Server
Product Form Factor
Rack-mountable - 1U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 1.2 and TPM 2.0)
Server Scalability
1-way
Hot-Swap Bays Qty
8
Localisation
Region: EMEA
Processor / Chipset
CPU
Intel Xeon E-2276G
Clock Speed
3.8 GHz
Max Turbo Speed
4.9 GHz
Number of Cores
6-core
CPU Qty
1
Max CPU Qty
1
Processor Main Features
Hyper-Threading Technology, Intel Virtualization Technology, Intel Turbo Boost Technology
Chipset Type
Intel C246
Cache Memory
Installed Size
12 MB
Cache Per Processor
12 MB
RAM
Installed Size
16 GB (installed) / 128 GB (max)
Technology
DDR4 SDRAM - ECC
Effective Memory Speed
2666 MHz
Rated Memory Speed
1333 MHz
Form Factor
DIMM 288-pin
Slots
4 (Total) / 3 (empty)
Features
Unbuffered
Configuration Features
1 x 16 GB
RAM Supported
128 GB - Intel Xeon E processors - unbuffered - ECC ¦ 64 GB unbuffered - ECC
Storage Controller
Type
1 x RAID
Controller Interface Type
SATA 6Gb/s
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
Matrox G200
Video Memory
16 MB
Video Interfaces
VGA
Networking
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5720
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
XClarity Controller (XCC) Standard
Features
PXE support, Teaming support
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5"
Slots
1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 (for internal storage controller) ¦ 1 (total) / 1 (free) x M.2 Card
Interfaces
1 x USB 2.0 (1 in front) ¦ 1 x USB 3.1 Gen 1 (1 in front) ¦ 2 x USB 3.1 Gen 2 ¦ 1 x serial ¦ 1 x VGA ¦ 1 x management - RJ-45 ¦ 2 x LAN (Gigabit Ethernet) - RJ-45
Miscellaneous
Included Accessories
Tool-less rail kit, C13-C14 rack power cable (2.8 m)
Compliant Standards
TUV GS, BSMI, EN 61000-3-2, ICES-003, EN 61000-3-3, EN55024, CB, CCC, RoHS, IEC 60950-1, EN 60950-1, FCC CFR47 Part 15 B, GB 17625.1, GB 9254 Class A, CECP, VCCI Class A, EN 50581, NMB-3 Class A, GB 4943.1, BIS, NOM-019, EK1-ITB2000, CNS 13438 Class A, KN35, AS/NZS CISPR 32 Class A, KN32 Class A, CNS 14336-1, EN 62368-1, IEC 62368-1, EN 55032 Class A, CISPR 32 Class A, TR CU 020/2011, TR CU 004/2011, UL 62368-1, CELP, CNS 15663
Power
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Installed Qty
1
Max Supported Qty
2
Voltage Required
AC 120/230 V (50/60 Hz)
Power Provided
450 Watt
Operating System / Software
OS Provided
No operating system
Sustainability Information
ENERGY STAR Certified
Yes
ENERGY STAR Version
2.1
Manufacturer Warranty
Service & Support
Limited warranty - 1 year - on-site - response time: next business day
Dimensions & Weight
Width
43.4 cm
Depth
49.8 cm
Height
4.3 cm
Weight
9.1 kg
