General
Device Type
NAS server
Host Connectivity
Gigabit Ethernet
Enclosure Type
Rack-mountable - 2U
Total Storage Capacity
16 TB
Max Supported Capacity
122 TB
Installed Devices / Modules Qty
8 (installed) / 14 (max)
Width
43.8 cm
Depth
51 cm
Height
8.85 cm
Weight
)
Localisation
Chinese (traditional), Chinese (simplified), English, German, French, Italian, Polish, Russian, Japanese, Korean
Processor / Memory
Processors Installed
1 x Intel Core i3 3.9 GHz
Number of Cores
Quad-Core
Max Supported Qty
1
RAM
8 GB (installed) / 64 GB (supported) - DDR4
Flash Memory Installed
8 GB
Storage Controller
Type
RAID
Interface Type
SATA 6Gb/s
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 5 hot spare, RAID 60
Hard Drive
Type
HDD - hot-swap
Capacity
8 x 2 TB
Networking
Data Link Protocol
10Mb LAN, 100Mb LAN, 1GbE
Network / Transport Protocol
NTP, iSCSI, SMTP, FTP, Bonjour
Remote Management Protocol
SNMP
Network Services Compatibility
Microsoft Active Directory (AD), File Level Security (ACLs), Microsoft CIFS, Network File System (NFS), FTP, Apple File Protocol (AFP), Web-based Distributed Authoring and Versioning (WebDAV), SFTP
Features
LDAP support, VLAN support, web server, Access Control List (ACL) support, bandwidth control, NTP time synchronisation, Dropbox support, anti-virus protection, system log, Google Drive support, Microsoft OneDrive support, FXP support, XMirror, Rsync compatible, auto port forwarding, WORM (Write Once Read Many protection)
Encryption Algorithm
SSL, TLS
Expansion / Connectivity
Expansion Bays
8 (total) / 0 (free) x hot-swap - 3.5" ¦ 6 (total) / 6 (free) x hot-swap - 2.5"
Expansion Slots
2 (total) / 2 (free) x expansion slot
Interfaces
4 x Ethernet 1000Base-T - RJ-45 ¦ 4 x USB 3.0 - Type A ¦ 1 x USB 2.0 - Type A ¦ 1 x HDMI output
Miscellaneous
Compliant Standards
VCCI, BSMI, SASO, FCC, EAC, RCM
Power
Power Device
Internal power supply
Installed Qty
2
Max Supported Qty
2
Power Redundancy
Yes
Power Redundancy Scheme
1+1
Voltage Required
AC 100 - 240 V (50/60 Hz)
Power Consumption Operational
263 Watt
Power Provided
250 Watt
Software / System Requirements
Storage Operating System
Linux
OS Required
UNIX, Apple MacOS X, Microsoft Windows, Linux 2.6 or later
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 80% (non-condensing)
