General
Product Type
Smartphone
Manufacturer Model Number
SM-G980F/DS
Form Factor
Touch
Protection
Dustproof, splashproof, water-resistant
Integrated Components
Heart rate sensor
Width
69.1 mm
Depth
7.9 mm
Height
151.7 mm
Weight
163 g
Body Colour
Cosmic grey
SAR Value
1.525 W/kg (body), 0.279 W/kg (head)
Cellular
Technology
TD-SCDMA / WCDMA (UMTS) / GSM
Mobile Broadband Generation
4G
Service Provider
Not specified
Operating System
Android 10
User Interface
Samsung One UI 2
Intelligent Assistant
Bixby
Navigation
GPS, GLONASS, BeiDou, Galileo
SIM Card Type
Nano SIM, Electronic SIM card (e-SIM)
SIM Card Qty
Dual-SIM
SIM Card Configuration Details
Nano SIM + nano SIM/microSD
Payment Technology
Samsung Pay
Input Device
Multi-touch, capacitive
Messaging & Internet
Messaging Services
SMS, MMS
Communications
Data Transmission
GPRS, EDGE, HSDPA, HSUPA, HSPA+, VoLTE, FDD-LTE, TDD-LTE, VoWiFi, LAA
2G Band
850 GSM, 900 GSM, 1800 GSM, 1900 GSM
3G UMTS Band
Band 1, Band 2, Band 4, Band 5, Band 8
3G UMTS Frequency
2100, 1900, 1700, 850, 900
4G LTE Band
Band 1, Band 2, Band 3, Band 4, Band 5, Band 7, Band 8, Band 12, Band 13, Band 17, Band 18, Band 19, Band 20, Band 25, Band 26, Band 28, Band 32, Band 38, Band 39, Band 40, Band 41, Band 66
4G LTE Frequency
FDD 2100, FDD 1900 PCS, FDD 1800+, FDD 1700 - 2110 AWS, FDD 850, FDD 2600, FDD 900, FDD 700a, FDD 700c, FDD 700b, FDD 800 lower, FDD 800 upper, FDD 800 DD, FDD 1900+, FDD 850+, FDD 700 APT, FDD 1500 L, TDD 2600, TDD 1900, TDD 2300, TDD 2500, FDD 1700 - 2110 AWS-3
Wireless Interface
NFC, IEEE 802.11a/b/g/n/ac, Bluetooth 5.0 LE, ANT+/ANT, IEEE 802.11a/b/g/n/ac/ax
Phone Features
Phone Functions
Speakerphone, voice control, call timer, conference call, flight mode, voice dialing, vibrating alert
Sensors
Accelerometer, proximity sensor, barometer, gyro sensor, hall sensor, RGB sensor, geomagnetic sensor, ultrasonic sensor, HR sensor
Security Devices
Fingerprint reader (under display), face recognition
Additional Features
HD Voice, Multi Window, Smart Select, MU-MIMO technology, Fast Charging, Samsung KNOX, High AOP Mic, Smart View, Live message, Samsung DeX support, Bixby Vision, Neural Network Processing Unit, Secure Folder function, Dual Audio, Bixby Routines, Intelligent Performance Enhancer, Samsung KNOX 3.3
Media Player
Supported Digital Audio Standards
WAV, WMA, AAC, PCM, AMR, MP3, FLAC, XMF, OGG, MIDI, APE (Monkey's Audio), M4A, DSF, MXMF, OGA, 3GA, AWB, IMY, RTTTL, RTX, OTA, DFF, MID, DSD64, DSD128
Supported Digital Video Standards
MKV, FLV, AVI, WMV, ASF, 3GP, M4V, WebM, 3G2, MP4
Sound Enhancements
Dolby Digital Plus sound, Dolby Atmos sound technology, Surround sound, Acoustic Overload Point, stereo speakers tuned by AKG, Dolby Digital sound, Qualcomm TrueWireless, Qualcomm Broadcast Audio, Qualcomm Aqstic audio, Qualcomm aptX audio
Processor
Type
Samsung Exynos 990
Clock Speed
2.73 GHz
Processor Core Qty
8-core
64-bit Architecture
Yes
Memory
RAM
LPDDR5 SDRAM - 8 GB
Internal Memory Capacity
128 GB
User Memory
104 GB
Supported Flash Memory Cards
microSDHC, microSDXC - up to 1 TB
Front Camera
Sensor Resolution
10 Megapixel
Lens Aperture
F/2.2
Focus Adjustment
Automatic
Field of View (FoV)
80 degree(s)
Camera Modes
Live Focus mode, AR Emoji, Live focus video
Features
Dual Pixel AF
Main Camera
Sensor Resolution
64 Megapixel
Optical Image Stabiliser
Optical Image Stabiliser (OIS)
Lens Type
Telephoto lens
Lens Aperture
F/2.0
Field of View (FoV)
76 degree(s)
Focus Adjustment
Automatic, manual
Self-Timer Delay
Yes
Special Effects
HDR, Grid Line, Motion photos
Camera Modes
Panorama, Slow motion mode, Pro mode, HYPERLAPSE, Super Slow-mo, Flowers, Greenery, Trees, Sky, Mountains, Beaches, Watersides, Snow, Backlit, Text, Food, Live focus with bokeh effect, Face, Baby, Person, Dog, Cat, People, Sunset, Sunrise, City, Waterfall, Scenery, Stage, Vehicles, Drinks, Animal, Shoes, Indoor, Clothes, Night view, Live focus video
Face Detection
Face detection
HDR Mode
HDR+
White Balance
Custom, automatic
Light Source
High CRI LED flash
Video Resolutions
1920 x 1080 (1080p) at 60 fps, 1280 x 720 (720p) at 30 fps, 3840 x 2160 (4K) at 60 fps, Super slow motion video 1280 x 720 (720p) at 960 fps, Slo-mo video 1920 x 1080 (1080p) at 240 fps, 7680 x 4320 (8K) at 24 fps
Features
Quick Launch, Playback zoom, Phase Detect Auto-Focus (PDAF), blink detection, VDIS (Video Digital Image Stabilisation), Tracking AF, Video location tags, location tags, Hyperlapse video support 1080p, Scene Optimiser, Full view, Flaw detection, Shot suggestions, AR Emoji, blur detection, HDR10+ recording, Floating shutter button, Super steady, Quick Measure, 3x Hybrid Zoom
Second Camera
Sensor Resolution
12 Megapixel
Lens Type
Ultra wide-angle lens
Lens Aperture
F/2.2
Field of View (FoV)
120 degree(s)
Pixel Size
1.4 µm
Features
Dual Pixel AF, OIS (Optical Image Stabilisation)
Third Camera
Sensor Resolution
12 Megapixel
Sensor Size
1/1.76"
Lens Type
Wide-angle lens
Lens Aperture
F/1.8
Field of View (FoV)
79 degree(s)
Pixel Size
1.8 µm
Features
Dual Pixel AF
Display
Type
OLED display
Technology
Infinity-O Dynamic AMOLED 2X
Diagonal Size
6.2"
Display Resolution
3200 x 1440 pixels
Display Format
QHD+
Pixel Density
563 ppi
HDR
Yes
HDR Technology
HDR10+
Refresh Rate
120 Hz
Protection
Corning Gorilla Glass 6 (scratch resistant glass)
Features
Edge Screen, DCI-P3 Wide colour gamut, AOD(Always On Display)
Connections
Connector Type
USB Type-C
Battery
Capacity
4000 mAh
Fast Charging Technology
Samsung Super Fast Charging 2.0
Wireless Charging
Yes
Wireless Charging Standards
WPC, PMA, Qi, Fast Wireless Charging 2.0, Wireless PowerShare
Run Time Details
Talk: up to 1200 min ¦ Active online usage (LTE): up to 14 hrs ¦ Active online usage (Wi-Fi): up to 15 hrs
Miscellaneous
Compliant Standards
VDE, IP68
Included Accessories
Power adapter, SIM card removal tool, USB-C cable, clear cover case, protective film, Earphones (USB Type-C) with sound by AKG
Manufacturer Warranty
Service & Support
Limited warranty - 2 years
