Camera
Type
Colour - Day&Night - fixed
Video Format
NTSC, PAL
Digital Video Format
MJPEG, H.264, H.265
Max Digital Video Resolution
2592 x 1944
Motion Detection
Yes
Exposure Range
1/5 sec - 1/12000 sec
Minimum Illumination
0.15 lux - colour - F2.0 ¦ 0 lux - B&W - infrared LEDs on
Infrared LEDs
Yes
Infrared Distance
20 m
Digital Video Capture Resolution
1280 x 720, 720 x 480, 640 x 480, 1280 x 960, 720 x 576, 800 x 600, 1920 x 1080, 640 x 360, 2592 x 1944, 800 x 448
Frame Rate (max)
30 frames per second
Features
Backlight Compensation (BLC), Wide Dynamic Range (WDR), Privacy Mask Function, Samsung Super Dynamic Range (SSDR), Lens Distortion Compensation (LDC), Variable Bitrate (VBR), Constant Bitrate (CBR), Multicast Streaming, auto gain control, auto white balance, Defocus Detection, ONVIF (Profile S) support, ONVIF (Profile G) support, Samsung Super Noise Reduction (SSNR), WiseStream II support, IP address filtering, motion detection, ONVIF (Profile T) support, direction detection
Lens Construction
Type
Motorized zoom
Optical Zoom
3.1 x
Focal Length
3.1 mm - 10 mm
Lens Iris
F/1.6-2.9
Horizontal Field of View (degree)
31.2 - 100.3
Vertical Field of View (degree)
23.5 - 72.3
Diagonal Field of View (degree)
38.8 - 133.1
Interfaces
Video
Composite video
Network Interface
Ethernet 10Base-T/100Base-TX
Network Protocols
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, IGMP, SSL, QOS, LLDP
Alarm Inputs Qty
1
Alarm Outputs Qty
1
