Product DescriptionAdvantech ARK-1000 Series ARK-1250L - fanless - box Core i5 1145G7E 1.5 GHz - 0 GB - no HDD
TypePC barebone - box
Processor1 x Intel Core i5 (11th Gen) 1145G7E / 1.5 GHz (up to 4.1 GHz, (Quad-Core)
Processor Main FeaturesIntel Turbo Boost Technology
Cache Memory8 MB
Cache Per Processor8 MB
RAM0 GB (installed) / 64 GB (max) - DDR4 SDRAM
Storage ControllerSATA (SATA 6Gb/s)
Hard DriveNo HDD
Optical StorageNo optical drive
Graphics ControllerIntel Iris Xe Graphics
Networking1GbE
OS ProvidedUbuntu Linux 20.04
Dimensions (WxDxH)17.3 cm x 14.1 cm x 6 cm
Weight1.5 kg
Manufacturer WarrantyLimited warranty - 2 years
Extended Specification
General
TypePC barebone
Product Form FactorBox
Built-in DevicesWatchdog timer
Processor / Chipset
CPUIntel Core i5 (11th Gen) 1145G7E
Clock Speed1.5 GHz
Max Turbo Speed4.1 GHz
Number of CoresQuad-Core
CPU Qty1
Max CPU Qty1
Processor Main FeaturesIntel Turbo Boost Technology
Cache Memory
Installed Size8 MB
Cache Per Processor8 MB
RAM
Installed Size0 GB (installed) / 64 GB (max)
TechnologyDDR4 SDRAM
Effective Memory Speed3200 MHz
Rated Memory Speed3200 MHz
Form FactorSO-DIMM 260-pin
Slots2 (Total) / 2 (empty)
Hard Drive
TypeNo HDD
Storage Controller
Type1 x SATA
Controller Interface TypeSATA 6Gb/s
Optical Storage
TypeNo optical drive
Monitor
Monitor TypeNone.
Graphics Controller
Graphics ProcessorIntel Iris Xe Graphics
Video InterfacesHDMI, VGA
Max Monitors Supported2
Audio Output
Compliant StandardsHigh Definition Audio
Networking
Ethernet Ports3 x Gigabit Ethernet
Ethernet Controller3 x Intel I225
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet
FeaturesWake on LAN (WoL)
Expansion / Connectivity
Bays1 (total) / 1 (free) x internal 2.5"
Slots2 (total) / 2 (free) x Mini PCIe/mSATA (full size / with SIM holder) ¦ 1 (total) / 1 (free) x M.2 Card (Key E)
Interfaces1 x VGA ¦ 1 x HDMI ¦ 3 x USB 3.2 - Type A ¦ 3 x USB 2.0 - Type A ¦ 4 x serial (RS-232/422/485) ¦ 1 x audio line-out - mini-jack ¦ 1 x audio line-in - mini-jack
Miscellaneous
Included AccessoriesDIN-rail bracket
Compliant StandardsCB, CCC, UL, FCC Class B certified, UKCA
