SQF MSATA 640 128G MLC (0-70C)
Manufacture#: SQF-SMSM4-128G-SBC
Checking delivery…
Product details
SSD
128 GB
internal
mSATA
Payment options available at checkout
Main features
Advantech SQFlash SQF-SMS 640
SSD
128 GB
internal
mSATA
SATA 6Gb/s
Overview
Advantech SQFlash 640 series mSATA delivers all the advantages of Flash Disk technology with the Serial ATA III (6.0Gb) interface, fully compliant with standard mSATA form factor. The SQF-SMS is based on the mSATA form factor which is generated by JEDEC and could provide a wide range capacity from 16GB to 1TBB for MLC and 8GB to 512GB for UltraMLC which delivers the read / write performance up to 560MB/s and 495MB/s.
Product Description
Advantech SQFlash SQF-SMS 640 - SSD - 128 GB - SATA 6Gb/s
Type
Solid state drive - internal
Capacity
128 GB
NAND Flash Memory Type
Multi-level cell (MLC)
Form Factor
mSATA
Interface
SATA 6Gb/s
Data Transfer Rate
600 MBps
Features
Shock resistant, Error Correction Code (ECC), Flash Security ID, Life Monitoring, Flash Lock, Emergency Erase, Fragment Writing Technology
Dimensions (WxDxH)
30 mm x 50.8 mm x 4.2 mm
General
Device Type
Solid state drive - internal
Capacity
128 GB
NAND Flash Memory Type
Multi-level cell (MLC)
Form Factor
mSATA
Interface
SATA 6Gb/s
Features
Shock resistant, Error Correction Code (ECC), Flash Security ID, Life Monitoring, Flash Lock, Emergency Erase, Fragment Writing Technology
Width
30 mm
Depth
50.8 mm
Height
4.2 mm
Performance
Drive Transfer Rate
600 MBps (external)
Expansion & Connectivity
Interfaces
1 x SATA 6 Gb/s - 52 pin mini-SATA
Compatible Bay
mSATA
Miscellaneous
Compliant Standards
FCC, RoHS
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
70 °C
Shock Tolerance (operating)
1500 g @ 0.5 ms
Vibration Tolerance (operating)
20 g @ 80-2000 Hz
