The Allied Telesis DMC100 series of Fast Ethernet mini media converters includes very small media converters which can easily fit into the palm of your hand. In addition to being compact - with a small carbon footprint - the DMC100 series can also be powered with the Micro USB to USB cable, and plugged directly into a laptop or PC. This saves installation time and cabling as there are no further power requirements.
Product DescriptionAllied Telesis AT DMC100/ST - fibre media converter - 100Mb LAN
Device TypeFibre media converter - RJ-45 / ST multi-mode
Form FactorDesktop
LocalisationEurope
Cabling Type100Base-FX, 100Base-TX
Data Transfer Rate100 Mbps
Optical Wave Length1310 nm
Data Link Protocol100Mb LAN
Max Transfer Distance2 km
Dimensions (WxDxH)3.18 cm x 9.14 cm x 2.16 cm
Weight113 g
Extended Specification
General
Device TypeFibre media converter
Form FactorDesktop
LocalisationEurope
Networking
Connectivity TechnologyWired
Cabling Type100Base-FX, 100Base-TX
Data Link Protocol100Mb LAN
Data Transfer Rate100 Mbps
Optical Wave Length1310 nm
Max Transfer Distance2 km
Status IndicatorsSystem, link/activity
FeaturesAuto-negotiation, VLAN support, auto-uplink (auto MDI/MDI-X), Smart Missing Link (SML), USB powered, Automatic Link Restoration
Compliant StandardsIEEE 802.1Q
Expansion / Connectivity
Interfaces1 x Ethernet 100Base-FX - ST multi-mode female x 2 ¦ 1 x Ethernet 100Base-TX - RJ-45 female
Miscellaneous
Compliant StandardsFCC Class A certified, VCCI, C-Tick, CISPR 22 Class A, EN 61000-3-2, EN 61000-3-3, EN55024, RoHS, UL 60950-1, EN 60950-1, EN 55022 Class A
