The ruggedized SDR series industrial power supply is a functional accessory for Allied Telesis products to build a solution suitable for smart cities (e.g., surveillance & security), industrial Ethernet, transportation or any application requiring systems that function in harsh environment with extended operating temperature.
Product DescriptionAllied Telesis AT-SDR120-48 - power supply - 120 Watt
Device TypePower supply - active Power Factor Correction (PFC) - external
Input Wiring1-phase 3 Wire
Input VoltageAC 115-230 V
Output Voltage48 V 48 - 55 V
Power Capacity120 Watt
Input Connectors3 pin captive screw
Dimensions (WxDxH)4 cm x 12.52 cm x 11.35 cm
Extended Specification
General
Device TypePower supply - active Power Factor Correction (PFC) - external
Power Device
Input VoltageAC 115-230 V
Input Voltage RangeAC 88 - 264 / DC 124 - 370 V
Input Voltage Margin+ 1% / - 1%
Input Wiring1-phase 3 Wire
Frequency Required47 - 63 Hz
Input Connectors3 pin captive screw
Output Voltage48 V 48 - 55 V
Max Electric Current2.5 A
Power Capacity120 Watt
Efficiency150% peak Load
Miscellaneous
MTBF1764.6 hours
FeaturesIP20 protection, 35 mm DIN rail, metal alloy case, overheat protection, over current protection, overload protection, NS 35 DIN rail
Compliant StandardsTUV, EN 61000-3-2, EN55024, EN 61000-4-2, EN 61000-6-2, UL 508, EN 61204-3, EAC, EN 61000-3, BSMI CNS 14336-1, EN 62368-1, CNS 13438 Class B, EN 61000-4, EN 55032/CISPR 32 Class A, EN 61204-3 Class B, SEMI F47, EN 61000-6, AS/NZS 62368.1, TP TC 004, TP TC 020
