The high density glass fabric PCB design reduces the gaps between the PCB layers to protect the motherboard against electrical shorts caused by humidity.
Expansion Slots1 x CPU ¦ 2 x DIMM 288-pin ¦ 1 x PCIe 3.0 x16 (x16 mode (with 1st and 2nd Generation Ryzen CPU); x8 mode (with Ryzen with Radeon Vega Graphics / AMD 7th Generation A-series CPU)) ¦ 1 x PCIe 2.0 x1
Storage InterfacesSATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10
Interfaces1 x PS/2 keyboard / mouse ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x VGA ¦ 1 x DVI-D ¦ 2 x USB 2.0 ¦ 4 x USB 3.1 Gen 1 ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack
Internal Interfaces4 x USB 2.0 - header ¦ 2 x USB 3.1 Gen 1 - header ¦ 1 x serial - header ¦ 1 x audio - header
Power Connectors4-pin ATX12V connector, 24-pin main power connector
Features
BIOS TypeAMI
BIOS FeaturesJumperFree, SMBIOS 2.3 support, UEFI BIOS, ACPI 5.1 support
Hardware MonitoringCPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage, opened case detection
Sleep / Wake UpWake on LAN (WOL)
Hardware FeaturesASRock Instant Flash, All-Solid Capacitor motherboard Design, ASRock APP Charger, 6 Phase Power Design, ASRock XFast LAN, ESD Protection, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), ELNA Audio Capacitors, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, ASRock Easy RAID Installer, Sapphire Black PCB, ASRock Live Update, ASRock Ultra M.2
Miscellaneous
Included Accessories1 x M.2 screw, I/O back cover
Cables Included2 x Serial ATA cable
Software IncludedDrivers & Utilities, Antivirus (Trial version), Google Chrome Browser, Google ChromeToolbar, ASRock APP Charger, ASRock XFast LAN
