ASROCK

B550 TAICHI ATX 4 DDR4 M4

Name: B550 TAICHI ATX 4 DDR4 M4
Brand: ASROCK
SKU: 1TCPTCOM-033098
Price: 257.4 GBP
Availability: OutOfStock

SKU

1TCPTCOM-033098

Manufacture#: 90-MXBD00-A0UAYZ

£214.50

£257.40 inc VAT

Checking delivery…

Product details

Motherboard
ATX
Socket AM4
AMD B550 Chipset

View full product specification

Notify me when this product is in stock

Payment options available at checkout

Compare product

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Overview

Main features

ASRock B550 Taichi
Motherboard
ATX
Socket AM4
AMD B550 Chipset
USB-C Gen2, USB 3.2 Gen 1, USB 3.2 Gen 2
2.5 Gigabit LAN, Wi-Fi, Bluetooth
onboard graphics (CPU required)
HD Audio (8-channel)

Overview

ASRock B550 Taichi motherboard is a reliable motherboard produced under ASRock's consistently stringent quality control. It delivers excellent performance with robust design conforming to ASRock's commitment to quality and endurance.

Specification

Product Description ASRock B550 Taichi - motherboard - ATX - Socket AM4 - AMD B550

Product Type Motherboard - ATX

Chipset Type AMD B550

Processor Socket 1 x Socket AM4

Compatible Processors Ryzen (supports 3rd Generation Ryzen and New Generation Ryzen with Radeon Graphics)

Max RAM Size 128 GB

RAM Supported 4 DIMM slots - DDR4, non-ECC, ECC (operate in non-ECC mode), unbuffered

Storage Ports 4 x SATA-600 (RAID), 4 x SATA-600, 2 x M.2

USB / FireWire Ports 1 x USB-C Gen 2 + 1 x USB 3.2 Gen 2 + 4 x USB 3.2 Gen 1 + 2 x USB 2.0 + (1 x USB-C Gen 2 + 4 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)

Max Allocated RAM Size 2 GB

Audio HD Audio (8-channel)

LAN 2.5 Gigabit Ethernet, 802.11a/b/g/n/ax, Bluetooth 5.1

Manufacturer Warranty 3-year warranty

General

Product Type Motherboard - ATX

Chipset Type AMD B550

Processor Socket Socket AM4

Max Processors Qty 1

Compatible Processors Ryzen (supports 3rd Generation Ryzen and New Generation Ryzen with Radeon Graphics)

Supported RAM

Max Size 128 GB

Technology DDR4

Bus Clock 2400 MHz, 2133 MHz, 2667 MHz, 2933 MHz, 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3800 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4200 MHz (O.C.), 4333 MHz (O.C.), 4600 MHz (O.C.), 4533 MHz (O.C.), 3200 MHz, 4666 MHz (O.C.), 4733 MHz (O.C.), 4466 MHz (O.C.)

Supported RAM Integrity Check Non-ECC, ECC (operate in non-ECC mode)

Registered or Buffered Unbuffered

Features Dual channel memory architecture, AMD Memory Profile (AMP), supported ECC modules operate in non-ECC mode

Graphics

Max Allocated RAM Size 2 GB

Audio

Type HD Audio (8-channel)

Audio Codec Realtek ALC1200

Compliant Standards High Definition Audio, Premium Blu-ray audio support

LAN

Network Controller Intel I225-V

Network Interfaces 2.5 Gigabit Ethernet, 802.11a/b/g/n/ax, Bluetooth 5.1

Expansion / Connectivity

Expansion Slots 1 x CPU ¦ 4 x DIMM 288-pin ¦ 3 x PCIe 4.0 x16 (PCIe 4.0 x16, x8/x8, x8/x8/PCIe 3.0 x4 modes (with Ryzen series CPUs Matisse); PCIe 3.0 x16, x8/x8, x8/x8/x4 modes (with Ryzen series CPUs Renoir)) ¦ 2 x PCIe 3.0 x1 ¦ 1 x M.2 socket (2230 M.2 Key E slot)

Storage Interfaces SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 ¦ ASMedia ASM1061: SATA-600 -connectors: 4 x 7pin Serial ATA ¦ PCIe 4.0 -connectors: 1 x M.2 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x Ultra M.2

Interfaces 1 x TOSLINK ¦ 1 x DisplayPort ¦ 1 x HDMI ¦ 1 x TOSLINK ¦ 2 x USB 2.0 ¦ 4 x USB 3.2 Gen 1 ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x USB 3.2 Gen 2 ¦ 1 x USB-C Gen2 ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (rear) - mini-jack

Internal Interfaces 4 x USB 2.0 - header ¦ 4 x USB 3.2 Gen 1 - header ¦ 1 x audio - header ¦ 1 x USB-C Gen2 - header

Power Connectors 24-pin main power connector, 2 x 8-pin ATX12V connectors

Features

BIOS Type AMI

BIOS Features JumperFree, SMBIOS 2.3 support, UEFI BIOS, ACPI 5.1 support

Hardware Monitoring CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage

Sleep / Wake Up Wake on LAN (WOL)

Hardware Features ASRock Instant Flash, HDCP compliant, 15µ Gold Contact, 16 Phase Power Design, ASRock Dr. Debug, AMD CrossFireX technology support, AMD Quad CrossFireX technology support, AMD 3-way CrossFireX technology support, Digi Power Design, ESD Protection, Gold Plated Audio Hardware, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), Clear CMOS Button, Direct Drive Technology, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, Dr.MOS MOSFET, XXL Aluminum Alloy Heatsink, Nahimic Audio Enhacer, I/O Armor, ASRock Live Update, Premium Memory Alloy Choke, Nichicon 12K Black Caps, Matte Black PCB, TI NE5532 Premium Headset Amplifier, Premium 60A Power Choke, 120dB SNR DAC with Differential Amplifier, Pure Power-In, PCB Isolate Shielding, ASRock Ultra USB Power, 2oz Copper PCB, ASRock Full Coverage M.2 Heatsink, ASRock Steel Slot Gen4, ASRock Hyper M.2

Miscellaneous

Included Accessories ASRock WiFi 2.4/5GHz Antenna, 2 x M.2 screws, screwdriver, 2 x standoff for M.2 socket

Cables Included 4 x Serial ATA cable

Software Included Drivers & Utilities, ASRock A-Tuning, Antivirus (Trial version), Google Chrome Browser, Google ChromeToolbar, ASRock XFast LAN, ASRock Polychrome SYNC

Compliant Standards Plug and Play, FCC, EuP Ready, ErP Ready, DisplayPort 1.4, HDCP 2.3

Width 30.5 cm

Depth 24.4 cm

Manufacturer Warranty

Service & Support Limited warranty - 3 years
