Network Interfaces2.5 Gigabit Ethernet, Bluetooth 5.3, 802.11a/b/g/n/ac/ax (Wi-Fi 6E)
Expansion / Connectivity
Expansion Slots1 x CPU ¦ 4 x DIMM 288-pin ¦ 1 x PCIe 4.0 x16 ¦ 1 x PCIe 4.0 x16 (x4 mode) ¦ 1 x PCIe 3.0 x16 (x1 mode) ¦ 1 x PCIe 3.0 x1 ¦ 1 x M.2 socket (2230 M.2 Key E slot) ¦ 3 x M.2 socket (2260/2280 M.2 Key M slot)
Storage InterfacesSATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 4.0 -connectors: 3 x M.2
Interfaces1 x HDMI ¦ 1 x DisplayPort ¦ 1 x USB-C 3.2 Gen 1 ¦ 5 x USB 3.2 Gen 1 ¦ 2 x USB 2.0 ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x microphone - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out (front surround) - mini-jack
Internal Interfaces1 x USB-C 3.2 Gen 2 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 2 x USB 2.0 - header ¦ 1 x SPI - header ¦ 1 x speaker - header ¦ 1 x audio - header ¦ 1 x Thunderbolt - header
Power Connectors4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector
Features
BIOS TypeAMI
BIOS FeaturesUEFI BIOS
Hardware FeaturesASRock Instant Flash, ESD Protection, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Easy RAID Installer, Dr.MOS MOSFET, ASRock EZ Mode, ASRock Intel 4-Layer Memory POOL (Planes on Outer Layers) Technology, ASRock RGB LED, Hi-Density Power Connectors, pre-mounted I/O shield, Intel Turbo Boost Max Technology 3.0, ASRock POST Status Checker (PSC), reinforced PCIe slots, Intel Hybrid Technology, ASRock Auto Driver Installer, 7+1+1 Phase Power Design, Intel Adaptive Boost Technology (ABT), Intel Thermal Velocity Boost (TVB), 50A Power Stage
Miscellaneous
Included Accessories3 x M.2 screws, standoff for M.2 socket, 2 x ASRock WiFi 2.4/5/6 GHz Antennas
