Registered or BufferedRegistered, Load-Reduced, 3DS Load-Reduced, 3DS registered, Optane DC Persistent
Features8-channel memory architecture, supports Intel Optane DC Persistent Memory (DCPMM)
Graphics
Graphics ControllerASPEED AST2500
LAN
Network ControllerIntel I210 / Intel X710-AT2
Network Interfaces2 x 10 Gigabit Ethernet, 2 x Gigabit Ethernet
Expansion / Connectivity
Expansion Slots1 x CPU ¦ 8 x DIMM 288-pin ¦ 3 x PCIe 4.0 x16 (x16 mode (x8 mode if PCI Express 4.0 x8 slot is occupied)) ¦ 1 x PCIe 4.0 x16 ¦ 3 x PCIe 4.0 x8
Storage InterfacesSATA-600 -connectors: 1 x mini-SAS HD - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ SATA-600 -connectors: 2 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ SATA-600 / PCIe 3.0 -connectors: 2 x M.2
Interfaces1 x VGA ¦ 2 x LAN (10Gigabit Ethernet) ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x management ¦ 4 x USB 3.2 Gen 1
Internal Interfaces1 x serial - header ¦ 2 x USB-C Gen2 - header ¦ 1 x USB 2.0 - Type A ¦ 2 x USB 3.2 Gen 1 - header ¦ 2 x USB 2.0 - header ¦ 2 x SGPIO - header ¦ 1 x serial - header ¦ 1 x LPC - header
Power Connectors4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector
Features
BIOS TypeAMI
BIOS FeaturesSMBIOS 2.3 support, UEFI BIOS, ACPI 5.0 support
Hardware MonitoringCPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage
Sleep / Wake UpWake on LAN (WOL)
Hardware FeaturesASRock Instant Flash, 7 Phase Power Design, Digi Power Design, ESD Protection, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), 2oz Copper PCB, 12 Layer PCB
Miscellaneous
Included AccessoriesI/O back plate, 2 x M.2 screws, non-fabric CPU carrier
Cables Included1 x mini SAS HD to 4 x SATA HDD cable ¦ 1 x Serial ATA cable
