Expansion / Connectivity
Expansion Slots
1 x CPU ¦ 4 x DIMM 288-pin ¦ 2 x PCIe 3.0 x16 (dual x8 mode; single card: x16 mode) ¦ 4 x PCIe 2.0 x1
Storage Interfaces
SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x Ultra M.2 ¦ SATA-600 / PCIe -connectors: 1 x M.2
Interfaces
1 x PS/2 keyboard / mouse ¦ 1 x USB 3.1 Gen 2 ¦ 1 x USB-C Gen2 ¦ 1 x HDMI ¦ 6 x USB 3.1 Gen 1 ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (front surround) - mini-jack ¦ 1 x TOSLINK
Internal Interfaces
4 x USB 2.0 - header ¦ 4 x USB 3.1 Gen 1 - header ¦ 1 x serial - header ¦ 1 x audio - header
Power Connectors
4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Type
AMI
BIOS Features
JumperFree, SMBIOS 2.3 support, UEFI BIOS, ACPI 5.1 support
Hardware Monitoring
CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage
Sleep / Wake Up
Wake on LAN (WOL)
Hardware Features
12 Phase Power Design, ASRock Instant Flash, HDCP compliant, NVIDIA Quad SLI Technology Support, NVIDIA 2-way SLI Technology Support, 15µ Gold Contact, ASRock XFast LAN, ASRock Dr. Debug, AMD CrossFireX technology support, AMD Quad CrossFireX technology support, Digi Power Design, ESD Protection, ASRock F-Stream, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), ASRock Key Master, Direct Drive Technology, ASRock Full Spike Protection, ASRock APP Shop, High Density Glass Fabric PCB, ASRock Full HD UEFI, ASRock Easy RAID Installer, XXL Aluminum Alloy Heatsink, Nichicon Fine Gold Series Audio Capacitors, I/O Armor, ASRock Live Update, ASRock Ultra M.2, Premium 45A Power Choke, Nichicon 12K Black Caps, Matte Black PCB, ASRock Steel Slots, TI NE5532 Premium Headset Amplifier, Hi-Density Power Connectors, 120dB SNR DAC with Differential Amplifier, Pure Power-In, PCB Isolate Shielding, 2oz Copper PCB
Miscellaneous
Included Accessories
I/O back plate, 2 x M.2 screws, ASRock SLI_HB_Bridge_2S Card
Software Included
Drivers & Utilities, Antivirus (Trial version), Google Chrome Browser, Google ChromeToolbar, ASRock XFast LAN, ASRock F-Stream, ASRock Polychrome RGB
Compliant Standards
Plug and Play, FCC, EuP Ready, ErP Ready
Width
30.5 cm
Depth
24.4 cm
