Expansion / Connectivity
Expansion Slots
1 x CPU ¦ 4 x DIMM 288-pin ¦ 2 x PCIe 3.0 x16 (x16/x4 mode (with AMD Ryzen CPU); x8/x2 mode (with AMD 7th Generation A-series/Athlon CPU)) ¦ 4 x PCIe 2.0 x1
Storage Interfaces
SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 ¦ ASMedia ASM1061: SATA-600 -connectors: 2 x 7pin Serial ATA ¦ PCIe 3.0 -connectors: 1 x Ultra M.2 ¦ SATA-600 -connectors: 1 x M.2
Interfaces
1 x PS/2 keyboard / mouse ¦ 1 x DVI-D ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x HDMI ¦ 5 x USB 3.1 Gen 1 ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x VGA ¦ 2 x USB 2.0 ¦ 1 x USB-C Gen1
Internal Interfaces
4 x USB 2.0 - header ¦ 2 x USB 3.1 Gen 1 - header ¦ 1 x serial - header ¦ 1 x audio - header
Power Connectors
24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Type
AMI
BIOS Features
Multilingual BIOS, JumperFree, SMBIOS 2.3 support, UEFI BIOS, ACPI 5.1 support
Hardware Monitoring
CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage
Sleep / Wake Up
Wake on LAN (WOL)
Hardware Features
ASRock Instant Flash, All-Solid Capacitor motherboard Design, 15µ Gold Contact, AMD CrossFireX technology support, AMD Quad CrossFireX technology support, ASRock Internet Flash, Digi Power Design, ESD Protection, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), LAN Cable Detection, ELNA Audio Capacitors, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, ASRock Easy RAID Installer, Sapphire Black PCB, ASRock Live Update, ASRock Ultra M.2, Premium 45A Power Choke, Premium Power Choke, 9 Phase Power Design, 2oz Copper PCB
Miscellaneous
Included Accessories
I/O back plate, 2 x M.2 screws
Cables Included
2 x Serial ATA cable
Software Included
Drivers & Utilities, ASRock A-Tuning, Antivirus (Trial version), Google Chrome Browser, Google ChromeToolbar, ASRock RGB LED, ASRock XFast LAN
Compliant Standards
Plug and Play, FCC, EuP Ready, ErP Ready
Width
30.5 cm
Depth
22.4 cm
