Expansion / Connectivity
Expansion Slots
1 x CPU ¦ 4 x DIMM 288-pin ¦ 2 x PCIe 4.0 x16 (PCIe 4.0 x16/x4 mode (with Ryzen series CPUs Matisse); PCIe 3.0 x16/x4 mode (with Ryzen series CPUs Pinnacle Ridge); PCIe 3.0 x8/x4 mode (with Ryzen series CPUs Picasso)) ¦ 2 x PCIe 4.0 x1 ¦ 1 x M.2 socket (Key E)
Storage Interfaces
SATA-600 -connectors: 8 x 7pin Serial ATA - 8 devices - RAID 0 / RAID 1 / RAID 10 ¦ PCIe 4.0 -connectors: 1 x M.2 - 1 devices ¦ SATA-600 / PCIe 4.0 -connectors: 1 x M.2 - 1 devices
Interfaces
2 x USB 3.2 Gen 2 ¦ 6 x USB 3.2 Gen 1 ¦ 1 x HDMI ¦ 1 x DisplayPort ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x audio line-out - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x PS/2 keyboard / mouse
Internal Interfaces
1 x serial - header ¦ 1 x Thunderbolt - header ¦ 1 x audio - header ¦ 2 x USB 2.0 - header ¦ 4 x USB 3.2 Gen 1 - header
Power Connectors
24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Type
AMI
BIOS Features
JumperFree, SMBIOS 2.3 support, UEFI BIOS, ACPI 5.1 support
Hardware Monitoring
CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage, power supply fan tachometer
Sleep / Wake Up
Wake on LAN (WOL)
Hardware Features
ASRock Instant Flash, HDCP compliant, 15µ Gold Contact, ASRock XFast LAN, Digi Power Design, ESD Protection, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), ELNA Audio Capacitors, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, ASRock Easy RAID Installer, Sapphire Black PCB, XXL Aluminum Alloy Heatsink, ASRock Live Update, 10 Phase Power Design, Premium 50A Power Choke, ASRock Steel Slots, PCB Isolate Shielding, 2oz Copper PCB, ASRock POST Status Checker (PSC)
Miscellaneous
Included Accessories
I/O back plate, 3 x M.2 screws
Cables Included
2 x Serial ATA cable
Software Included
Antivirus (Trial version), Google Chrome Browser, Google ChromeToolbar, ASRock XFast LAN, ASRock Polychrome SYNC
Compliant Standards
Plug and Play, FCC, EuP Ready, ErP Ready
Width
30.5 cm
Depth
22.9 cm
