Expansion / Connectivity
Expansion Slots
1 x CPU ¦ 4 x DIMM 288-pin ¦ 3 x PCIe 4.0 x16 (PCIe 4.0 x16, x8/x8, x8/x8/x4 modes (with Ryzen series CPUs Matisse); PCIe 3.0 x16, x8/x8, x8/x8/PCIe 4.0 x4 modes (with Ryzen series CPUs Pinnacle Ridge); PCIe 3.0 x8 or PCIe 4.0 x4 mode (with Ryzen series CPUs Raven Ridge and Picasso)) ¦ 2 x PCIe 4.0 x1 ¦ 1 x M.2 socket (Key E)
Storage Interfaces
SATA-600 -connectors: 8 x 7pin Serial ATA - 8 devices - RAID 0 / RAID 1 / RAID 10 ¦ PCIe 4.0 -connectors: 1 x M.2 - 1 devices ¦ SATA-600 / PCIe 4.0 -connectors: 2 x M.2 - 2 devices
Interfaces
1 x USB 3.2 Gen 2 ¦ 1 x USB-C Gen2 ¦ 6 x USB 3.2 Gen 1 ¦ 1 x HDMI ¦ 1 x TOSLINK ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x audio line-out - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x PS/2 keyboard / mouse ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x audio line-out (front surround) - mini-jack
Internal Interfaces
1 x USB-C Gen2 - header ¦ 1 x Thunderbolt - header ¦ 1 x audio - header ¦ 4 x USB 2.0 - header ¦ 2 x USB 3.2 Gen 1 - header
Power Connectors
4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Type
AMI
BIOS Features
JumperFree, SMBIOS 2.3 support, UEFI BIOS, ACPI 5.1 support
Hardware Monitoring
CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage, power supply fan tachometer
Sleep / Wake Up
Wake on LAN (WOL)
Hardware Features
NVIDIA SLI Technology Support, ASRock Instant Flash, HDCP compliant, Digital PWM, NVIDIA Quad SLI Technology Support, 15µ Gold Contact, ASRock XFast LAN, AMD CrossFireX technology support, AMD Quad CrossFireX technology support, ESD Protection, Gold Plated Audio Hardware, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), Clear CMOS Button, Direct Drive Technology, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, ASRock Easy RAID Installer, Dr.MOS MOSFET, XXL Aluminum Alloy Heatsink, Nichicon Fine Gold Series Audio Capacitors, I/O Armor, ASRock Live Update, ASRock Hyper BCLK Engine II, Premium Memory Alloy Choke, Nichicon 12K Black Caps, Matte Black PCB, ASRock Steel Slots, ASRock Purity Sound 4, TI NE5532 Premium Headset Amplifier, Premium 60A Power Choke, Pure Power-In, PCB Isolate Shielding, Combo Caps, ASRock Ultra USB Power, 2oz Copper PCB, NVIDIA NVLink, ASRock POST Status Checker (PSC), ASRock Full Coverage M.2 Heatsink
Miscellaneous
Included Accessories
I/O back plate, ASRock WiFi 2.4/5GHz Antenna, 3 x M.2 screws, ASRock SLI_HB_Bridge_2S Card, screwdriver, 3 x standoff for M.2 socket
Cables Included
4 x Serial ATA cable
Software Included
Drivers & Utilities, Antivirus (Trial version), Google Chrome Browser, Google ChromeToolbar, ASRock XFast LAN, ASRock Polychrome SYNC
Compliant Standards
Plug and Play, FCC, EuP Ready, ErP Ready
Width
30.5 cm
Depth
24.4 cm
