Expansion / Connectivity
Expansion Slots
1 x CPU ¦ 4 x DIMM 288-pin ¦ 2 x PCIe 4.0 x16 (PCIe 4.0 x16, x8/x8 modes (with Ryzen series CPUs Vermeer, Matisse); PCIe 3.0 x16, x8/x8 modes (with Ryzen series CPUs Pinnacle Ridge, APUs Renoir); PCIe 3.0 x8 mode (with Ryzen series APUs Picasso)) ¦ 1 x PCIe 4.0 x16 (x4 mode) ¦ 1 x PCIe 4.0 x1 ¦ 1 x M.2 socket (Key E)
Storage Interfaces
SATA-600 -connectors: 8 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 ¦ PCIe 4.0 -connectors: 1 x M.2 - 1 devices ¦ SATA-600 / PCIe 4.0 -connectors: 2 x M.2 - 2 devices
Interfaces
1 x USB 3.2 Gen 2 ¦ 1 x USB-C Gen2 ¦ 4 x USB 3.2 Gen 1 ¦ 1 x HDMI ¦ 1 x TOSLINK ¦ 2 x USB 2.0 ¦ 1 x audio line-out - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x microphone - mini-jack ¦ 1 x PS/2 keyboard / mouse ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x LAN (2.5Gigabit Ethernet)
Internal Interfaces
1 x USB-C Gen2 - header ¦ 1 x Thunderbolt - header ¦ 1 x audio - header ¦ 4 x USB 2.0 - header ¦ 4 x USB 3.2 Gen 1 - header
Power Connectors
24-pin main power connector, 2 x 8-pin ATX12V connectors
Features
BIOS Type
AMI
BIOS Features
JumperFree, SMBIOS 2.3 support, UEFI BIOS, ACPI 5.1 support
Hardware Monitoring
CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage, power supply fan tachometer
Sleep / Wake Up
Wake on LAN (WOL)
Hardware Features
NVIDIA SLI Technology Support, ASRock Instant Flash, Digital PWM, NVIDIA Quad SLI Technology Support, 15µ Gold Contact, 16 Phase Power Design, ASRock Dr. Debug, AMD CrossFireX technology support, AMD Quad CrossFireX technology support, AMD 3-way CrossFireX technology support, ESD Protection, Gold Plated Audio Hardware, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), Clear CMOS Button, Direct Drive Technology, WIMA film capacitors, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, Dr.MOS MOSFET, XXL Aluminum Alloy Heatsink, Killer DoubleShot Pro, Nahimic Audio Enhacer, I/O Armor, ASRock Live Update, Premium Memory Alloy Choke, Nichicon 12K Black Caps, Matte Black PCB, Premium 60A Power Choke, Pure Power-In, PCB Isolate Shielding, ASRock Ultra USB Power, 2oz Copper PCB, NVIDIA NVLink, ESS 9218 SABRE HiFi DAC, ASRock Full Coverage M.2 Heatsink, ASRock Steel Slot Gen4, ASRock Hyper M.2
Miscellaneous
Included Accessories
ASRock WiFi 2.4/5GHz Antenna, 3 x M.2 screws, screwdriver, 2 x standoff for M.2 socket
Cables Included
4 x Serial ATA cable
Software Included
Drivers & Utilities, ASRock A-Tuning, Antivirus (Trial version), Google Chrome Browser, Google ChromeToolbar, ASRock Killer LAN, Razer Synapse 3
Compliant Standards
Plug and Play, FCC, EuP Ready, ErP Ready, HDCP 2.3
Width
30.5 cm
Depth
24.4 cm
