Expansion / Connectivity
Expansion Slots
1 x CPU ¦ 2 x DIMM 288-pin ¦ 2 x PCIe 5.0 x16 (dual x8 mode; single card: x16 mode) ¦ 1 x PCIe 4.0 x16 (x4 mode) ¦ 1 x M.2 socket (for wireless module) ¦ 1 x PCIe 3.0 x1
Storage Interfaces
SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 4.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 5 ¦ SATA-600 / PCIe 4.0 -connectors: 2 x M.2 - RAID 0 / RAID 1 / RAID 5
Interfaces
1 x HDMI ¦ 1 x PS/2 keyboard / mouse ¦ 2 x USB 3.2 Gen 2 ¦ 2 x Thunderbolt 4/USB4 ¦ 2 x USB 3.2 Gen 1 ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x microphone - mini-jack ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x TOSLINK ¦ 2 x DisplayPort input ¦ 1 x LAN (10Gigabit Ethernet)
Internal Interfaces
4 x USB 2.0 - header ¦ 2 x USB-C Gen 2x2 - header ¦ 4 x USB 3.2 Gen 1 - header ¦ 1 x audio - header
Power Connectors
24-pin main power connector, 6-pin ATX12V connector, 2 x 8-pin ATX12V connectors
Features
BIOS Type
AMI
BIOS Features
UEFI BIOS, SMBIOS 2.7 support, ACPI 6.0 support
Hardware Monitoring
CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU overheating protection, CPU core voltage
Sleep / Wake Up
Wake on LAN (WOL)
Hardware Features
ASRock Instant Flash, 15µ Gold Contact, 20 Phase Power Design, ASRock Internet Flash, Digi Power Design, ESD Protection, Gold Plated Audio Hardware, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), Status OLED, V-Probe, Direct Drive Technology, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Easy RAID Installer, XXL Aluminum Alloy Heatsink, Killer DoubleShot Pro, Nahimic Audio Enhacer, ASRock Live Update, ASRock EZ Mode, Premium Memory Alloy Choke, Nichicon 12K Black Caps, Matte Black PCB, ASRock Steel Slots, Premium Power Choke, Pure Power-In, PCB Isolate Shielding, 2oz Copper PCB, pre-mounted I/O shield, Intel Turbo Boost Max Technology 3.0, 12 Layer PCB, ESS 9218 SABRE HiFi DAC, shaped PCB design, ASRock Full Coverage M.2 Heatsink, AQUA Cooling Armor, ASRock Hyper M.2, ASRock USB 3.2 Gen2, ASRock USB 4.0, WIMA audio capacitors, Server-Grade Low-Loss PCB, Windows 11 compatible, 105A Smart Power Stage, Intel Hybrid Technology, ASRock Auto Driver Installer, ASRock Hyper BCLK Engine V
Miscellaneous
Included Accessories
3 x M.2 screws, thermal grease, ASRock WiFi 2.4/5/6 GHz aerial, digital leak detector, 9 x thermal pads, 4 x screws for MOS, 4 x screws for CPU sockets
Cables Included
4 x Serial ATA cable
Software Included
Drivers & Utilities, ASRock A-Tuning, Antivirus (Trial version), ASRock Polychrome SYNC, Killer Control Center
Compliant Standards
FCC, EuP Ready, ErP Ready, CEC Tier II
Width
30.5 cm
Depth
26.7 cm
