Expansion / Connectivity
Expansion Slots
1 x CPU ¦ 4 x DIMM 288-pin ¦ 3 x PCIe 5.0 x16 (dual: x8 mode; triple: x8, x8, x4 mode; single card: x16 mode) ¦ 1 x PCIe 3.0 x1 ¦ 1 x M.2 socket (Key E)
Storage Interfaces
SATA-600 -connectors: 6 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ SATA-600 -connectors: 1 x 7pin Serial ATA ¦ SATA-600 / PCIe 3.0 -connectors: 1 x M.2 - RAID 0 / RAID 1 / RAID 5 ¦ PCIe 4.0 -connectors: 2 x Hyper M.2 - RAID 0 / RAID 1 / RAID 5
Interfaces
1 x LAN (Gigabit Ethernet) ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 4 x USB 3.2 Gen 1 ¦ 2 x USB 3.2 Gen 2 ¦ 2 x Thunderbolt 4/USB4 ¦ 1 x HDMI ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x TOSLINK ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (rear) - mini-jack
Internal Interfaces
4 x USB 3.2 Gen 1 - header ¦ 1 x USB-C Gen 2x2 - header ¦ 3 x USB 2.0 - header ¦ 1 x audio - header ¦ 1 x USB 3.2 Gen 1 - Type A
Power Connectors
24-pin main power connector, 2 x 8-pin ATX12V connectors
Features
BIOS Type
AMI
BIOS Features
Multilingual BIOS, UEFI BIOS, SMBIOS 2.7 support, ACPI 6.0 support
Hardware Monitoring
CPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, system voltage, CPU core voltage
Sleep / Wake Up
Wake on LAN (WOL)
Hardware Features
ASRock Instant Flash, 15µ Gold Contact, 20 Phase Power Design, AMD CrossFireX technology support, ASRock Internet Flash, Digi Power Design, ESD Protection, Gold Plated Audio Hardware, Energy Efficient Ethernet 802.3az, Preboot eXecution Environment (PXE), 8 Layer PCB, Direct Drive Technology, ASRock A-Tuning, ASRock Full Spike Protection, ASRock APP Shop, ASRock Super Alloy, High Density Glass Fabric PCB, ASRock Full HD UEFI, ASRock My Favorites in UEFI, ASRock Easy RAID Installer, XXL Aluminum Alloy Heatsink, Killer DoubleShot Pro, Nahimic Audio Enhacer, I/O Armor, ASRock Live Update, ASRock EZ Mode, Premium Memory Alloy Choke, Nichicon 12K Black Caps, Matte Black PCB, ASRock Steel Slots, Pure Power-In, ASRock Ultra USB Power, 2oz Copper PCB, Intel Turbo Boost Max Technology 3.0, ESS 9218 SABRE HiFi DAC, ASRock Full Coverage M.2 Heatsink, DIY Friendly Design, Premium 90A Power Choke, ASRock Hyper M.2, ASRock USB 3.2 Gen2, ASRock USB 4.0, WIMA audio capacitors, Server-Grade Low-Loss PCB, Surface Mount Technology (SMT), Intel Hybrid Technology, ASRock Auto Driver Installer, ASRock Hyper BCLK Engine V, Smart Power Stage (SPS) technology
Miscellaneous
Included Accessories
3 x M.2 screws, standoff for M.2 socket, graphics card holder, wireless dongle USB bracket, 1 x 3010 cooling fan with bracket and screw package, 1 x 4010 cooling fan bracket and screw package, ASRock WiFi 2.4/5/6 GHz aerial
Cables Included
4 x Serial ATA cable
Software Included
Drivers & Utilities, ASRock A-Tuning, Antivirus (Trial version), Google Chrome Browser, Google ChromeToolbar, ASRock Polychrome SYNC, Killer Control Center
Compliant Standards
FCC, EuP Ready, ErP Ready, CEC Tier II
Width
30.5 cm
Depth
24.4 cm
