ESC4000A-E10/1600W TOWER BAREBONE AMD EPYC
Manufacture#: 90SF01A1-M01230
£2730.97
£3277.16 inc VAT
Checking delivery…
Product details
- Server
- rack-mountable
- 2U
- 1-way
Payment options available at checkout
Main features
- ASUS ESC4000A-E10
- Server
- rack-mountable
- 2U
- 1-way
- no CPU
- RAM 0 GB
- SATA
- hot-swap 2.5", 3.5" bay(s)
- no HDD
- AST2500
- GigE
- no OS
- monitor: none
Overview
This 2U single-socket GPU server supports up to 8 GPUs, 8 DIMM, PCIe 4.0, M.2, NVMe, OCP 3.0, Dual LAN, and max. TDP up to 280 W.
Product Description
ASUS ESC4000A-E10 - rack-mountable - no CPU - 0 GB - no HDD
Type
Server - rack-mountable
Height (Rack Units)
2U
Server Scalability
1-way
Processor
No CPU
Processor Socket
Socket SP3
RAM
0 GB (installed) / 2 TB (max) - DDR4 SDRAM
Storage Controller
SATA
Server Storage Bays
Hot-swap 2.5", 3.5"
Hard Drive
No HDD
Optical Storage
No optical drive
Graphics Controller
ASPEED AST2500
Networking
GigE
Power
(50/60 Hz)
Power Redundancy
Yes
OS Provided
No operating system
Dimensions (WxDxH)
44 cm x 80 cm x 8.89 cm
Weight
34 kg
General
Type
Server
Product Form Factor
Rack-mountable - 2U
Server Scalability
1-way
Hot-Swap Bays Qty
8
Processor / Chipset
CPU
No CPU
Max CPU Qty
1
CPU Upgradability
Upgradable
CPU Socket
Socket SP3
RAM
Installed Size
0 GB / 2 TB (max)
Technology
DDR4 SDRAM
Form Factor
DIMM 288-pin
Slots
8 (Total) / 8 (empty)
Features
Registered, Load-Reduced DIMM (LRDIMM), 8-channel memory architecture, 3DS Load-Reduced DIMM (LRDIMM)
RAM Supported
2 TB registered
Storage Controller
Type
1 x SATA
Optical Storage
Type
No optical drive
Monitor
Monitor Type
None.
Graphics Controller
Graphics Processor
ASPEED AST2500
Video Interfaces
VGA
Networking
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
Intel I350-AM2
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Aspeed AST2500
Features
KVM over IP support
Expansion / Connectivity
Bays
8 (total) / 8 (free) x hot-swap 2.5" / 3.5" shared
Slots
4 (total) / 4 (free) x PCIe 4.0 x16 - full-length, full-height (x16/x8 mode) ¦ 4 (total) / 4 (free) x PCIe 4.0 x16 - full-length, full-height (x8 mode) ¦ 2 (total) / 2 (free) x PCIe 4.0 x16 - half-length, low-profile ¦ 1 (total) / 1 (free) x PCIe 4.0 x8 - half-length, low-profile ¦ 1 (total) / 1 (free) x M.2 Card - 2242/2260/2280/22110
Interfaces
2 x LAN (Gigabit Ethernet) ¦ 1 x management (NIC) - RJ-45 ¦ 6 x USB 3.2 Gen 1 (4 front, 2 rear) ¦ 1 x VGA
Miscellaneous
Compliant Standards
FCC Class A certified, BSMI, RCM
Power
Device Type
Power supply
Power Redundancy
Yes
Power Redundancy Scheme
1+1
Installed Qty
2
Max Supported Qty
2
Voltage Required
AC 100-127/200-240 V (50/60 Hz)
Power Provided
1600 Watt
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Provided
No operating system
Dimensions & Weight
Width
44 cm
Depth
80 cm
Height
8.89 cm
Weight
34 kg
Dimensions & Weight (Shipping)
Shipping Weight
44 kg
Environmental Parameters
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
