General
Product Type
Motherboard - ATX
Chipset Type
Intel Z590
Processor Socket
LGA1200 Socket
Max Processors Qty
1
Compatible Processors
(supports 11th and 10th Generation Intel Core / Pentium Gold / Celeron)
Supported RAM
Max Size
128 GB
Technology
DDR4
Bus Clock
2400 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3400 MHz (O.C.), 3333 MHz (O.C.), 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4500 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4600 MHz (O.C.), 4700 MHz (O.C.), 4800 MHz (O.C.), 3200 MHz, 5000 MHz (O.C.), 5333 MHz (O.C.), 5133 MHz (O.C.)
Supported RAM Integrity Check
Non-ECC
Registered or Buffered
Unbuffered
Features
Dual channel memory architecture, Intel Extreme Memory Profiles (XMP)
Audio
Type
HD Audio (8-channel)
Audio Codec
Realtek ALC4080
Compliant Standards
High Definition Audio, DTS Sound Unbound
LAN
Network Controller
Intel I225-V / Intel AX210
Network Interfaces
802.11a/b/g/n/ac/ax, 2 x 2.5 Gigabit Ethernet
Expansion / Connectivity
Expansion Slots
1 x CPU ¦ 4 x DIMM 288-pin ¦ 2 x PCIe 4.0 x16 (dual x8/x8, x8/x4 modes; single card: x16 mode; PCIe 4.0 (11th Gen Intel CPUs), PCIe 3.0 (10th Gen Intel CPUs)) ¦ 1 x PCIe 3.0 x16 (x4 mode)
Storage Interfaces
SATA-600 -connectors: 6 x 7pin Serial ATA ¦ PCIe 4.0 -connectors: 2 x M.2 ¦ SATA-600 / PCIe 3.0 -connectors: 2 x M.2
RAID Features
Intel Rapid Storage Technology
Interfaces
2 x USB 2.0 ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 4 x USB 3.2 Gen 1 ¦ 1 x HDMI ¦ 1 x DisplayPort ¦ 1 x USB-C Gen2 ¦ 2 x USB 3.2 Gen 2 ¦ 1 x USB-C Gen2x2 ¦ 1 x audio line-out (center/subwoofer) - mini-jack ¦ 1 x audio line-out (rear) - mini-jack ¦ 1 x TOSLINK ¦ 2 x LAN (2.5Gigabit Ethernet)
Internal Interfaces
2 x USB 3.2 Gen 1 - header ¦ 1 x audio - header ¦ 4 x USB 2.0 - header ¦ 1 x USB-C Gen 2x2 - header ¦ 1 x Thunderbolt 4 - header
Power Connectors
4-pin ATX12V connector, 24-pin main power connector, 8-pin ATX12V connector
Features
BIOS Type
AMI
BIOS Features
BIOS FlashBack, UEFI BIOS, ASUS EZ Flash 3
Sleep / Wake Up
Wake on LAN (WOL), wake on PME
Hardware Features
CrashFree BIOS 3, ASUS EPU (Energy Processing Unit), NVIDIA 2-way SLI Technology Support, Intel Turbo Boost Technology 2.0, ASUS TPU (TurboV Processing Unit), ASUS DIGI+ VRM, SupremeFX Shielding technology, Gold Plated Audio Hardware, Preboot eXecution Environment (PXE), Clear CMOS Button, ASUS Fan Xpert 4, Intel Optane Memory Ready, Sonic Radar III, Sonic Studio III, Intel Turbo Boost Max Technology 3.0, ASUS Aura Sync, Armoury Crate, ASUS OptiMem III, FlexKey button, GameFirst VI, Savitech SV3H712 amplifier
Miscellaneous
Included Accessories
Cable ties, 40mm fan, ROG fan stickers, ROG VGA holder, ROG thank you card, ROG key chain, ASUS Wi-Fi moving aerial, M.2 Q-Latch, 2 x M.2 rubber package
Cables Included
4 x Serial ATA cable
Software Included
Drivers & Utilities, ROG CPU-Z, ASUS AI Suite III, ASUS EZ Update, ASUS Turbo App, Overwolf, Antivirus, WinRAR, ASUS ROG RAMCache III, Sonic Studio Virtual Mixer, AIDA64 Extreme (60 days trial), MemTest86
Compliant Standards
DisplayPort 1.4
Width
30.5 cm
Depth
24.4 cm
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
