General
Device Type
Wireless router - 4-port switch (integrated)
Enclosure Type
Desktop
Connectivity Technology
Wireless, wired
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E)
Frequency Band
2.4 GHz / 5 GHz / 6 GHz
Data Transfer Rate
7800 Mbps
Performance
Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 4804 Mbps ¦ Maximum data rate (6 GHz): 2402 Mbps
Capacity
QoS rules/classes: 32 ¦ MAC filter entries: 64 ¦ Firewall keyword filters: 64 ¦ Firewall network service filters: 32 ¦ Firewall URL filters: 64
Network / Transport Protocol
PPTP, L2TP, IPSec, PPPoE, RTSP
Encryption Algorithm
WPA-Enterprise, WPA2-Enterprise, WPS, WPA3-Personal, WPA2-Personal, WPA-Personal
Wi-Fi Rating
AX7800
Features
WOL, MAC address filtering, IPv6 support, URL filtering, parental control, dual WAN connection, RADIUS support, SSH support, IPSec passthrough, DHCP server, Samba support, FTP server, port forwarding, ASUS AiDisk, reset button, port triggering, 3G/4G USB Dongle Support, ASUS AiCloud, ASUSWRT, L2TP passthrough, ASUS AiProtection, MU-MIMO technology, system log, beamforming technology, Adaptive QoS, Link Aggregation, Wireless Scheduler, Tri-Band, VPN Fusion, Airtime Fairness, DMZ support, Traffic Analyser, traffic monitoring, ASUS AiMesh, Explicit Beamforming, Bandwidth Limiter, ASUS AiProtection Pro, OpenVPN client, PPTP VPN client, OFDMA, OpenVPN server, IPTV support, WPS button, NAT passthrough, 160MHz bandwidth support, RTSP Pass-Through, H.323 Pass-Through, SIP Pass-Through, PPPoE relay, auto firmware update, Guest Network, AiMesh node mode, ASUS Instant Guard, Android tethering, Let's Encrypt, Quad-core CPU, external HDD hibernation, Bandwidth Monitor, Malicious Site Blocker, shared folder permission, DDNS, L2TP VPN client, IPSec VPN server, PPTP VPN server, login captcha
Compliant Standards
REACH, FCC Part 15 Class B
Processor
1 x 1.7 GHz
RAM
512 MB
Flash Memory
256 MB
Status Indicators
Power, WAN, LAN, 5 GHz, 2.4 GHz, 6 GHz
