General
Device Type
Network surveillance camera
Audio Support
Yes: two-way audio via edge-to-edge technology, built-in microphone
Audio Formats
AAC, G.711, OPUS, LPCM
Form Factor
Dome
Connectivity Technology
Wired
Width
14.9 cm
Depth
14.9 cm
Height
10.2 cm
Weight
791 g
Localisation
English, German, French, Spanish, Italian, Russian, Chinese (simplified), Japanese, Korean, Portuguese, Polish, Chinese (traditional)
Camera
Type
Colour - Day&Night - fixed - outdoor - vandal / waterproof
Digital Video Format
H.264, MPEG-4 Part 10, H.265, MPEG-H Part 2, MJPEG
Max Digital Video Resolution
2688 x 1512
Motion Detection
Yes
Exposure Range
1/5 sec - 1/50000 sec
Minimum Illumination
0.16 lux - colour - F2.0 - 50 IRE ¦ 0 lux - B&W - F2.0 - 50 IRE - infrared LEDs on
Infrared Distance
30 m
Digital Video Capture Resolution
2688 x 1512, 2304 x 1728, 160 x 90, 160 x 120
Frame Rate (max)
60 frames per second
RAM
1024 MB
Flash Memory
8192 MB
Features
Infrared-cut filter, deep learning processing unit (DLPU), Zipstream technology, Adaptive Bitrate (ABR), Variable Bitrate (VBR), Multi-Bitrate (MBR), saturation control, contrast control, brightness control, sharpness control, Forensic WDR, white balance, exposure zone, tone mapping, exposure mode, defogging, barrel distortion correction, compression, 180° image rotation, 270° image rotation, 90° image rotation, image mirror, dynamic text overlay, image overlay, polygon privacy mask, digital PTZ function, network speaker pairing, password protection, IP address filtering, HTTPs encryption, Access Control, digest authentication, user access log, centralised certificate management, brute force delay protection, signed firmware, secure boot, secure keystore, Axis device ID, Axis Edge Vault, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, VoIP support, Wide Dynamic Range (WDR), video streaming indicator, night shift, day shift, e-mail alerts, plastic housing, sunshield
Image Sensor
Type
4 MP PS RGB CMOS 1/2.7"
Lens Construction
Type
Fixed focal
Focal Length
2.9 mm
Lens Iris
F/2.0 fixed iris
Horizontal Field of View (degree)
102
Vertical Field of View (degree)
73
Panning
Range (degree)
-190 to +190
Tilting
Range (degree)
-10 to +80
Interfaces
Network Interface
Ethernet 10Base-T/100Base-TX
Network Protocols
EAP, TLS, IPv4, IPv6, USGv6, ICMP, HTTP, HTTPS, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, RTSP, RTCP, RTP, SRTP, TCP/IP, UDP/IP, IGMP, IGMPv2, IGMPv3, DHCP, ARP, SOCKS, SSH, SIP, LLDP, CDP, MQTT, Syslog, Zeroconf
Alarm Inputs Qty
1
Alarm Outputs Qty
1
Expansion / Connectivity
Ports
LAN/power - RJ-45 ¦ Audio line-in/microphone - 3.5 mm jack ¦ Digital input/output - terminal block
Supported Memory Cards
microSD Card, microSDHC Card, microSDXC Card
Miscellaneous
Included Accessories
Drill hole template, terminal block connectors, cable gaskets, connector guard, weathershield, Resitorx TR20 screw bit
Compliant Standards
IEEE 802.1x, EAL 4, IEC/EN 60529 IP66, NEMA Type 4X, IEC/EN 62262 IK10, IEEE 802.3af, IEEE 802.3at, EN 55032 Class A, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), KCC KN35, KN32 Class A, AS/NZS CISPR 32 Class A, RCM, VCCI Class A, IEC/EN/UL 62368-1, IEC/EN/UL 60950-22, IEC 62471, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, NEMA TS-2 (2.2.7-2.2.9), NIST SP500-267
Colour
White, NCS S 1002-B
Power
Power Requirements
DC 12 V / PoE
Power Device
4.8 Watt
Software / System Requirements
Software Included
Windows decoder 1-user licence, AXIS Companion, AXIS Camera Station
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
50 °C
Relative Humidity (operating)
5 - 95% RH (non-condensing)
