AXIS

AXIS M4328-P .

Name: AXIS M4328-P .
Brand: AXIS
SKU: 1TSECSPD-006280
Price: 774.08 GBP
Availability: InStock

SKU

1TSECSPD-006280

Manufacture#: 02637-001

£645.07

£774.08 inc VAT

Checking delivery…

Product details

Network panoramic camera
fisheye
indoor
colour (Day&Night)

View full product specification

Payment options available at checkout

Compare product

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Overview

Main features

AXIS M4328-P
Network panoramic camera
fisheye
indoor
colour (Day&Night)
12 MP
2992 x 2992
fixed iris
fixed focal
audio
LAN 10/100
H.264B, H.264M, H.264H, H.265, MJPEG
PoE Class 3
TAA Compliant

Overview

Offering 180°/360° coverage and no blind spots, this fisheye camera supports advanced analytics based on deep learning on the edge. Its ultra-compact size makes it ideal for wherever you need high-quality indoor surveillance.

Specification

Product Description AXIS M4328-P - network panoramic camera - fisheye - TAA Compliant

Device Type Network panoramic camera - fixed - fisheye - indoor

Audio Yes: two-way audio capability

Dimensions (WxDxH) 10.1 cm x 10.1 cm x 5.1 cm

Weight 300 g

Colour White, NCS S 1002-B

Connectivity Technology Wired

Camera Colour - Day&Night

Max Resolution 2992 x 2992

Frame Rate (max) 30 frames per second

Motion Detection Yes

Optical Sensor Type RGB CMOS - 1/2.3" - 12 MP

Minimum Illumination 0.19 lux - colour - F2.2 - 50 IRE ¦ 0.04 lux - B&W - F2.2 - 50 IRE

Focal Length Control Fixed focal

Focal Length 1.2 mm

Focus Adjustment Fixed focus

Lens Iris F/2.2 - fixed iris

Interfaces Ethernet 10Base-T/100Base-TX

Voltage PoE Class 3

Features Progressive scanning, IR Corrected lens, infrared-cut filter, deep learning processing unit (DLPU), Zipstream technology, Adaptive Bitrate (ABR), Multi-Bitrate (MBR), Variable Bitrate (VBR), video streaming indicator, Forensic WDR, Spatio-temporal noise filtering, 2D Noise Reduction Technology, 3D Noise Reduction Technology, saturation control, contrast control, brightness control, sharpness control, tone mapping, white balance, day/night threshold, exposure mode, exposure zone, compression, image mirror, dynamic text, image overlay, polygon privacy mask, digital PTZ function, guard tour, Corridor mode, network speaker pairing, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Privacy Mask Function, Pixel Counter Support, digital roll, level grid, signed firmware, brute force delay protection, digest authentication, password protection, memory card encryption, Axis Edge Vault, Axis device ID, secure keystore, signed video, secure boot, IP address filtering, Lightfinder technology

TAA Compliant Yes

Manufacturer Warranty 5-year warranty

Environmental Parameters (operating) 0 °C - 40 °C; 10 - 85% RH (non-condensing) relative humidity

General

Device Type Network panoramic camera

Audio Support Yes: two-way audio capability

Form Factor Fisheye

Connectivity Technology Wired

Width 10.1 cm

Depth 10.1 cm

Height 5.1 cm

Weight 300 g

Localisation Argentina, Australia, Brazil, China, European Union, Japan, Korea, United Kingdom

Camera

Type Colour - Day&Night - fixed - indoor

Digital Video Format H.264B, H.264M, H.264H, H.265, MJPEG

Max Digital Video Resolution 2992 x 2992

Motion Detection Yes

Exposure Range 1/2 sec - 1/8100 sec

Minimum Illumination 0.19 lux - colour - F2.2 - 50 IRE ¦ 0.04 lux - B&W - F2.2 - 50 IRE

Digital Video Capture Resolution 2992 x 2992, 3840 x 2160, 192 x 72, 3584 x 2688, 384 x 288, 2048 x 1536, 256 x 144, 3200 x 1600, 2880 x 2880, 2560 x 1920

Frame Rate (max) 30 frames per second

RAM 2 GB

Flash Memory 8 GB

Image Sensor

Type 12 MP RGB CMOS 1/2.3"

Lens Construction

Type Fixed focal

Focal Length 1.2 mm

Lens Iris F/2.2 fixed iris

Focus Adjustment Fixed focus

Horizontal Field of View (degree) 182

Vertical Field of View (degree) 182

Interfaces

Network Interface Ethernet 10Base-T/100Base-TX

Network Protocols IPv4, IPv6, ICMP, HTTP, HTTPS, TLS, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, NTS, RTSP, RTP, SRTP, TCP/IP, UDP/IP, IGMP, IGMPv2, IGMPv3, RTCP, DHCP, SSH, LLDP, CDP, MQTT, Syslog, Zeroconf, SIP

Expansion / Connectivity

Ports LAN - RJ-45

Supported Memory Cards microSD Card, microSDHC Card, microSDXC Card

Miscellaneous

Included Accessories Owner authentication key

TAA Compliant Yes

Compliant Standards IEEE 802.1x, IEEE 802.1ar, CSA, UL/cUL, BIS, UKCA, KC, EN 55032 Class A, EN 55035, EN 61000-6-1, EN 61000-6-2, RCM, AS/NZS CISPR 32 Class A, ICES-3(A)/NMB-3(A), VCCI Class A, KS C 9835, KS C 9832 Class A, FCC Part 15 B Class A, IEC/EN/UL 62368-1, CAN/CSA-C22.2 No. 62368-1 Third Edition, IS 13252, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, NIST SP500-267, X.509, IEEE 802.3af, IEEE 802.3at, PVC-free, BFR-free, CFR free, RoHS 2011/65/EU, EN 63000:2018, REACH 2006/1907

Colour White, NCS S 1002-B

Power

Power Requirements PoE Class 3

Software / System Requirements

Software Included AXIS Object Analytics, AXIS Video Motion Detection

Manufacturer Warranty

Service & Support Limited warranty - 5 years

Environmental Parameters

Min Operating Temperature 0 °C

Max Operating Temperature 40 °C

Relative Humidity (operating) 10 - 85% RH (non-condensing)
