General
Device Type
Network surveillance camera
Audio Support
Yes: two-way audio capability
Audio Formats
PCM, G.726, ADPCM, AAC-LC, LPCM, G.711, OPUS
Form Factor
Dome
Camera Mount Type
Wall mount, ceiling mount
Connectivity Technology
Wired
Width
14.9 cm
Depth
14.9 cm
Height
10.3 cm
Weight
800 g
Camera
Type
Colour - Day&Night - fixed - outdoor
Digital Video Format
MJPEG, H.264, HEVC, H.265, MPEG-4 AVC
Max Digital Video Resolution
2592 x 1944
Motion Detection
Yes
Exposure Range
1/5 sec - 1/33500 sec
Minimum Illumination
0.13 lux - colour - F1.3 - 50 IRE ¦ 0 lux - B&W - F1.3 - 50 IRE
Infrared LEDs
Yes
Infrared Distance
40 m
Video Capture
2592 x 1944 @ 30 fps
RAM
512 MB
Flash Memory
1024 MB
Features
Sharpness control, white balance, progressive scanning, saturation control, brightness control, contrast control, image mirror, Privacy Mask Function, full duplex audio, digital PTZ function, password protection, IR Corrected lens, Variable Bitrate (VBR), Audio Detection, OptimizedIR, Zipstream technology, remote focus, ONVIF (Profile S) support, ONVIF (Profile G) support, image overlay, exposure control, infrared-cut filter, Forensic WDR, IP address filtering, secure boot, ONVIF (Profile T) support, Adaptive Bitrate (ABR), Lightfinder 2.0 technology, motion-adaptive exposure
Image Sensor
Type
5 MP RGB CMOS 1/2.7"
Lens Construction
Type
Vari-focal
Optical Zoom
2.7 x
Focal Length
3 mm - 8 mm
Lens Iris
F/1.3 auto iris (P-Iris)
Horizontal Field of View (degree)
40 - 104
Vertical Field of View (degree)
29 - 74
Panning
Range (degree)
-180 to +180
Tilting
Range (degree)
-75 to +75
Interfaces
Network Interface
Ethernet 10Base-T/100Base-TX/1000Base-T
Network Protocols
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, SOCKS, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, SMB, IGMP, SSH, SSL, QOS, CIFS, SRTP, EAP, SFTP, SIP, LLDP, USGv6, MQTT
Expansion / Connectivity
Ports
LAN/power - RJ-45 ¦ Audio line-in/microphone - terminal block
Supported Memory Cards
microSD Card, microSDHC Card, microSDXC Card
Miscellaneous
Included Accessories
Cable gaskets, drill hole template, Resistorx T20 tool L-key, weathershield, connector guard, terminal block connectors
Compliant Standards
EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, IEC 60068-2-27, IEC 60068-2-6, FCC Part 15 B Class A, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-78, KC, VCCI Class A, RCM, IS13252, KN35, NEMA250 Type 4X, AS/NZS CISPR 32 Class A, KN32 Class A, EN 55032 Class A, IEC/EN 62471, IEEE 802.3af, IEEE 802.3at, EN 55035, IEC/EN/UL 62368-1, IEC/EN 60529 IP66, IEEE 802.1x, NIST SP500-267, ICES-3(A)/NMB-3(A), IEC/EN 62262 IK10
Colour
White
Power
Power Requirements
DC 12 V / PoE Plus
Power Device
6.5 Watt
Software / System Requirements
Software Included
Windows decoder 1-user licence
Manufacturer Warranty
Service & Support
Limited warranty - 5 years
Environmental Parameters
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Relative Humidity (operating)
10 - 85% (non-condensing)
