AXIS

AXIS Q6318-LE 50 Hz - network surveillance camera

Name: AXIS Q6318-LE 50 Hz - network surveillance camera
Brand: AXIS
SKU: 1TSECSPD-005017
Price: 3820.92 GBP
Availability: InStock

SKU

1TSECSPD-005017

Manufacture#: 02446-002

£3184.10

£3820.92 inc VAT

Checking delivery…

Product details

Network surveillance camera
PTZ
outdoor
vandal / weatherproof

View full product specification

Payment options available at checkout

Compare product

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Overview

Main features

AXIS Q6318-LE 50 Hz
Network surveillance camera
PTZ
outdoor
vandal / weatherproof
colour (Day&Night)
3840 x 2160
4K
auto iris
motorized
GbE
H.264B, H.264M, H.264H, H.265, MJPEG
High PoE Class 6

Overview

Ideal for city surveillance, AXIS Q6318-LE features a 1/2" sensor and 31x optical zoom. With laser focus, it offers precise focus every time - even in the dark. It includes all the functionality you need to track and identify suspect behavior.

Specification

Product Description AXIS Q6318-LE 50 Hz - network surveillance camera

Device Type Network surveillance camera - pan / tilt / zoom - outdoor - vandal / weatherproof

Dimensions (WxDxH) 19.2 cm x 19.2 cm x 26.1 cm

Weight 4.8 kg

Colour White, NCS S 1002-B

Connectivity Technology Wired

Camera Colour - Day&Night

Optical Zoom 31 x

Max Resolution 3840 x 2160

Frame Rate (max) 30 frames per second

Motion Detection Yes

Video Modes 4K

Optical Sensor Type PS CMOS - 1/2"

Minimum Illumination 0.11 lux - colour - F1.36 - 30 IRE ¦ 0.001 lux - B&W - F1.36 - 30 IRE ¦ 0 lux - IR ¦ 0.25 lux - colour - F1.36 - 50 IRE ¦ 0.009 lux - B&W - F1.36 - 50 IRE

Focal Length Control Motorized zoom

Focal Length 6.91 mm - 214.64 mm

Focus Adjustment Automatic

Lens Iris F/1.36-4.6 - auto iris (P-Iris)

Panning Range (degree) 360

Tilting Range (degree) -90 to +20

Interfaces Ethernet 10Base-T/100Base-TX/1000Base-T

Voltage AC 100-240 V, High PoE Class 6

Features Laser focus, infrared-cut filter, 300 preset positions, adjustable zoom speed, control queue, guard tour, Machine learning processing unit (MLPU), Nadir flip, on-screen directional indicator, quick-zoom, set new pan 0°, speed dry, tour recording, Zipstream technology, Adaptive Bitrate (ABR), Multi-Bitrate (MBR), Variable Bitrate (VBR), low latency mode, video streaming indicator, Electronic Image Stabilizer (EIS), Forensic WDR, Privacy Mask Function, centralised certificate management, IP address filtering, user access log, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, VAPIX support, Advanced Gatekeeper, autotracking 2, orientation aid PTZ, Axis device ID, Axis Edge Vault, brute force delay protection, digest authentication, memory card encryption, password protection, secure boot, secure keystore, signed firmware, signed video, Sharpdome technology, OptimizedIR, Trusted Platform Module (TPM), aluminium housing

Manufacturer Warranty 5-year warranty

Environmental Parameters (operating) 50 °C; 10 - 100% RH (condensing) relative humidity

General

Device Type Network surveillance camera

Connectivity Technology Wired

Width 19.2 cm

Depth 19.2 cm

Height 26.1 cm

Weight 4.8 kg

Localisation European Union

Camera

Type Colour - Day&Night - pan / tilt / zoom - outdoor - vandal / weatherproof

Digital Video Format H.264B, H.264M, H.264H, H.265, MJPEG

Max Digital Video Resolution 3840 x 2160

Motion Detection Yes

Video Modes 4K

Digital Zoom 12

Exposure Range 1/5 sec - 1/8500 sec

Minimum Illumination 0.11 lux - colour - F1.36 - 30 IRE ¦ 0.001 lux - B&W - F1.36 - 30 IRE ¦ 0 lux - IR ¦ 0.25 lux - colour - F1.36 - 50 IRE ¦ 0.009 lux - B&W - F1.36 - 50 IRE

Infrared LEDs Yes

Infrared Distance 200 m

Digital Video Capture Resolution 3840 x 2160

Frame Rate (max) 30 frames per second

RAM 2 GB

Flash Memory 512 MB

Image Sensor

Type PS CMOS 1/2"

Lens Construction

Type Motorized zoom

Optical Zoom 31 x

Focal Length 6.91 mm - 214.64 mm

Lens Iris F/1.36-4.6 auto iris (P-Iris)

Focus Adjustment Automatic

Horizontal Field of View (degree) 2.3 - 58.5

Vertical Field of View (degree) 1.4 - 34.9

Panning

Range (degree) 360

Speed (degree/sec) Up to 550

Tilting

Range (degree) -90 to +20

Speed (degree/sec) Up to 500

Interfaces

Network Interface Ethernet 10Base-T/100Base-TX/1000Base-T

Network Protocols IPv4, IPv6, USGv6, ICMP, HTTP, HTTPS, TLS, QOS, FTP, SFTP, CIFS, SMB, SMTP, Bonjour, UPnP, SNMP 1, SNMP 2c, SNMP 3, DNS, DDNS, NTP, NTS, RTSP, RTCP, RTP, SRTP, RTSPS, TCP/IP, UDP/IP, IGMP, IGMPv2, IGMPv3, DHCP, ARP, SSH, NTCIP, LLDP, MQTT, Syslog, Zeroconf

Expansion / Connectivity

Ports LAN - RJ-45

Supported Memory Cards SD Memory Card, SDXC Memory Card, SDHC Memory Card

Miscellaneous

Included Accessories IP66-rated RJ45 connector kit, template, paint paper

Compliant Standards EAL 4+, FIPS 140-2 Level 2, IEEE 802.1x, IEEE 802.1ar, TLS v1.2, TLS v1.3, X.509, PVC-free, AES-256, EN 55032 Class A, EN 55035, IEC 62236-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), VCCI Class A, AS/NZS CISPR 32 Class A, CISPR 35, EAC, EN 50121-4, KS C 9832 Class A, KS C 9835, IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1 Third Edition, IEC/EN 62471, IEC 60825-1 Class 1, IS 13252, IEC/EN 62262 IK10, IEC/EN 60529 IP66, IEC/EN 60529 IP67, NEMA250 Type 4X, NEMA TS-2 (2.2.7-2.2.9), IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, ISO 21207 method B, NIST SP500-267

Colour White, NCS S 1002-B

Power

Power Requirements High PoE Class 6

Power Device Power injector - external AC 100-240 V 17 Watt

Software / System Requirements

Software Included AXIS Object Analytics, AXIS Video Motion Detection, AXIS Motion Guard, AXIS Fence Guard, AXIS Loitering Guard, AXIS OSDI Zones, Windows decoder 1-user licence

Manufacturer Warranty

Service & Support Limited warranty - 5 years

Environmental Parameters

Max Operating Temperature 50 °C

Relative Humidity (operating) 10 - 100% RH (condensing)
