Power Device
Input Voltage
AC 100-240 V
Frequency Required
50 - 60 Hz
Power Output Connectors Details
1 x power 24 pin ATX with detachable 4 pin section ¦ 1 x power 4+4 pin - 12 V ¦ 1 x power P8 - 12 V ¦ 1 x 12VHPWR 600 W ¦ 4 x 8 pin PCI Express power with detachable 2 pin section ¦ 12 x 15 pin Serial ATA power ¦ 3 x Parallel ATA
Output Voltage
+3.3, +5, ±12 V
Power Capacity
750 Watt
Output Current
+3.3V - 22 A ¦ +5V - 22 A ¦ +12V1 - 25 A ¦ +12V2 - 25 A ¦ +12V3 - 30 A ¦ +12V4 - 30 A ¦ -12V - 0.5 A ¦ +5VSB - 3 A
Efficiency
72.2% at 2% Load (230 VAC), 91.8% at 10% Load (230 VAC), 94.8% at 20% Load (230 VAC), 95.8% at 50% Load (230 VAC), 93.8% at 100% Load (230 VAC)
Power Factor (PF)
0.98
Modular Cable Management
Yes
80 PLUS Certification
80 PLUS Titanium
Miscellaneous
Included Accessories
Thumbscrews, screws, cable ties, overclock slot bracket with switch, overclock jumper
Cooling System
135 mm fan
Features
Silent Wings, Modern Standby, sleeved cables, overclock mode, overheat protection, over current protection, overpower protection, short-circuit protection, over voltage protection, undervoltage protection, Surge & Inrush Protection (SIP), 4 x 12V rail, Active Rectifier, LLC resonant converter technology, switchable single/multi 12V rails, Synchronous Rectifier (SR) technology, DC-DC technology, Full Bridge topology, fluid dynamic bearing cooling fan, fully modular
Compliant Standards
BSMI, CB, CCC, cTUVus, CU, FCC, RCM, TUV, UKCA, ERP, WEEE, RoHS, Triman
