General
Device Type
Multifunction printer
Fax Type
Plain paper
Printing Technology
Ink-jet - colour
Monthly Duty Cycle (max)
5000 pages
Recommended Monthly Volume
50 - 1500 pages
Display Diagonal Size
2.7"
Display Colour Support
Colour
Display Features
Touch screen
Connection Availability
Yes
Interface
USB 2.0, LAN, Wi-Fi(n), USB host, NFC
AirPrint Enabled
Yes
Office Machine Features
Print from memory card, print from USB flash drive, scan to e-mail, scan to network, scan to FTP, scan to memory card, scan to SharePoint, scan to OCR, scan to USB host
Localisation
United Kingdom
Memory
Standard Memory
128 MB
Supported Flash Memory
SD Memory Card, MultiMediaCard, USB flash drive, MultiMediaCardplus, SDHC Memory Card, SDXC Memory Card
Copying
Max Copying Speed
Up to 6 ppm (mono) / up to 6 ppm (colour)
Max Copying Resolution
Up to 1200 x 2400 dpi (mono) / up to 1200 x 2400 dpi (colour)
Max Copying Resolution Class
Up to 1200 x 2400 dpi (mono) / up to 1200 x 2400 dpi (colour)
Max Document Enlargement
400%
Max Document Reduction
25%
Maximum Copies
99
Printing
Nozzle Configuration
210 nozzles (black), 3 x 210 nozzles (cyan, magenta, yellow)
Max Printing Resolution
Up to 1200 x 6000 dpi (mono) / up to 1200 x 6000 dpi (colour)
Max Printing Resolution Class
Up to 1200 x 6000 dpi (mono) / up to 1200 x 6000 dpi (colour)
Max Printing Speed
Up to 12 ppm (mono) / up to 10 ppm (colour)
Ink Cartridge Configuration
4 cartridges (1 each: cyan, magenta, yellow, black)
Ink Palette Supported (Colours)
Cyan, magenta, yellow, black
Colour
4-ink
Minimum Ink Droplet Size
1.5 pl
Ink Type
Brother Innobella ink
Automatic Duplexing
Yes
First Print Out Time B/W
8 sec
First Print Out Time Colour
8.5 sec
Scanning
Scan Element
CIS
Optical Resolution
1200 x 2400 dpi
Interpolated Resolution
19200 x 19200 dpi
Grayscale Depth
8-bit
Colour Depth
24-bit
Colour Depth (Internal)
30-bit
Scanning Resolution Details
1200 x 600 dpi - ADF ¦ 1200 x 2400 dpi - flatbed
Fax Machine
Compatibility
G3
Max Transmission Speed
14.4 Kbps
Fax Resolutions
203 x 98 dpi, 203 x 196 dpi, 203 x 392 dpi
Reception Memory Capacity
Up to 180 pages
Transmission Memory Capacity
Up to 180 pages
PC Faxing
Yes
Fax Machine Features
Error Correction Mode (ECM)
Yes
Broadcast Transmission
250 stations
Features
Group dialling
Document & Media Handling
Max Original Size
Legal (216 x 356 mm)
Supported Original Sizes
Legal (216 x 356 mm), A4 (210 x 297 mm), 148 x 148 mm
Original Type
Sheets
Document Feeder Capacity
20 sheets
Max Media Size
A4/Letter
Min Media Weight
64 g/m²
Max Media Weight
300 g/m²
Supported Media Type
Envelopes, plain paper, recycled paper, coated paper, glossy paper
Supported Media Sizes
ANSI A (Letter) (216 x 279 mm), Executive (184 x 267 mm), A4 (210 x 297 mm), A5 (148 x 210 mm), A6 (105 x 148 mm), 100 x 150 mm, 130 x 180 mm, 90 x 130 mm, 130 x 200 mm
Supported Envelope Sizes
International DL (110 x 220 mm), Com-10 (105 x 241 mm), International C5 (162 x 229 mm), Monarch (98.4 x 190.5 mm)
Standard Media Capacity
150 sheets
Bypass Feeder Capacity
1 sheet
Output Trays Capacity
50 sheets
Document & Media Handling Details
Input tray - 150 sheets weight: 64 g/m² - 220 g/m² ¦ ADF - 20 sheets size: 148 x 148 mm - Legal (216 x 356 mm) ¦ Output tray - 50 sheets ¦ Bypass tray - 1 sheet weight: 64 g/m² - 300 g/m²
Speed Details
Printing: up to 27 ppm (A4) - B/W ¦ Printing: up to 23 ppm (A4) - colour ¦ Printing: up to 12 ipm - B/W (ISO/IEC 24734) ¦ Printing: up to 10 ipm - colour (ISO/IEC 24734) ¦ Printing: up to 3 ipm - B/W duplex (ISO/IEC 24734) ¦ Printing: up to 3 ipm - colour duplex (ISO/IEC 24734) ¦ Copying: up to 6 ipm - B/W (ISO/IEC 24735) ¦ Copying: up to 6 ipm - colour (ISO/IEC 24735) ¦ Scanning: up to 12 ipm - B/W (ISO/IEC 17991) ¦ Scanning: up to 6 ipm - colour (ISO/IEC 17991)
Connections
Interfaces
1 x USB 2.0 - 4 pin USB Type B ¦ 1 x USB host - 4 pin USB Type A ¦ 1 x LAN - RJ-45
Security Protocols & Features
Kerberos, SSL, WEP, WPA-PSK, TLS, IPsec, 802.1x, WPA2-PSK, WPS, Wi-Fi Direct, SNMP 3
Operating System Support
Linux, MS Windows Server 2008 R2 x64 Edition, MS Windows Server 2012 x64 Edition, Android, iOS, MS Windows Server 2008 (32/64-bits), MS Windows Server 2012 R2 x64 Edition, MS Windows 7 (32/64 bits), Windows 8 (32/64-bits), Windows 8.1 (32/64-bits), Windows Phone, Windows 10 (32/64-bits), Apple Mac OS X 10.11, macOS 10.12, MS Windows Server 2016, macOS 10.13, Windows 10 in S mode
Software Included
Brother ControlCenter4, Brother ControlCenter2 for Mac, ScanSoft PaperPort SE 12 with OCR
Power
Voltage Required
AC 230 V (50/60Hz)
Power Consumption Operational
20 Watt
Power Consumption Standby
4 Watt
Power Consumption Sleep
1.3 Watt
Miscellaneous
Consumables Included
1 x ink cartridge (black) - up to 6000 pages ISO/IEC 19752 - Brother LC3235XLBK ¦ 1 x ink cartridge (cyan) - up to 5000 pages ISO/IEC 19752 - Brother LC3235XLC ¦ 1 x ink cartridge (magenta) - up to 5000 pages ISO/IEC 19752 - Brother LC3235XLM ¦ 1 x ink cartridge (yellow) - up to 5000 pages ISO/IEC 19752 - Brother LC3235XLY
Environmental Standards
ENERGY STAR Certified
Yes
Blue Angel Compliant
Yes
Manufacturer Warranty
Service & Support
Limited warranty - 3 years
Dimensions & Weight
Width
43.5 cm
Depth
34.1 cm
Height
19.5 cm
Weight
8.8 kg
Dimensions & Weight (Shipping)
Shipping Width
51.2 cm
Shipping Depth
27.2 cm
Shipping Height
47 cm
Shipping Weight
10.1 kg
Environmental Parameters
Sound Emission
50 dBA (operating)
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 80% (non-condensing)
