General
Device Type
Switch - 12 ports
Bundled Services
Cisco DNA Subscription
Enclosure Type
Rack-mountable 1U
Subtype
10 Gigabit Ethernet
Ports
12 x 1 Gigabit / 10 Gigabit SFP+
Performance
SD-WAN IPsec throughput (1400Bytes, clear text): 51 Gbps ¦ SD-WAN IPsec throughput (IMIX, clear text): 22.6 Gbps ¦ IPv4 forwarding throughput (1400-byte packet size): 118 Gbps ¦ IPsec throughput (1400Bytes, clear text): 84 Gbps
Capacity
SD-WAN overlay tunnels scale: 8000 ¦ IPsec SVTI tunnels: 4000 ¦ ACLs per system: 4000 ¦ Access Control Entries (ACEs) per system (IPv4): 47000 ¦ IPv4 routes: 4000000 ¦ IPv6 routes: 4000000 ¦ Queues: 256000 ¦ NAT sessions: 12000000 ¦ Firewall sessions: 6000000 ¦ Virtual Routing and Forwarding (VRF) entries: 8000
Routing Protocol
OSPF, IS-IS, RIP-1, RIP-2, BGP, EIGRP, HSRP, DVMRP, VRRP, PIM-SM, static IP routing, IGMPv3, GRE, OSPFv3, PIM-SSM, policy-based routing (PBR), MPLS, Bidirectional Forwarding Detection (BFD), RSVP, LISP
Remote Management Protocol
SNMP, SSH, CLI, SCP, NETCONF, NTP, DHCP, IPv4, IPv6, RADIUS, OMP
Encryption Algorithm
DES, Triple DES, SHA, MD5, IKE, TLS, PKI, 128-bit AES, 256-bit AES, DTLS, 1024-bit RSA, 2048-bit RSA, 256-bit SHA, 512-bit SHA, 748-bit RSA, 384-bit SHA, ECDSA 256-bit, ECDSA 384-bit
Authentication Method
Secure Shell (SSH), RADIUS
Features
Firewall protection, NAT support, VPN support, VLAN support, Syslog support, Class-Based Weighted Fair Queuing (CBWFQ), Weighted Random Early Detection (WRED), Access Control List (ACL) support, Quality of Service (QoS), DHCP server, DHCP relay, NTP server, DHCP client, Virtual Routing and Forwarding (VRF), Forward Error Correction (FEC), IPFIX, Flexible NetFlow (FNF), MACsec support, Application Visibility and Control (AVC), TrustSec support, Authentication, Authorization and Accounting (AAA), DNS client, IP Security (IPSec) support, Encapsulated Remote SPAN (ERSPAN), Embedded Event Manager (EEM), Ethernet Virtual Connections (EVC), Cisco IOS IP Service-Level Agreements (IPSLA), Network-Based Application Recognition (NBAR), L2TP support, Point-to-Point Protocol (PPP), High-Level Data Link Control (HDLC), Multilink Point-to-Point Protocol (MLPPP), Performance Routing (PfR), SD-WAN support, Application Aware Routing (AAR), DNS support, Secure Unique Device Identification (SUDI)
Compliant Standards
IEEE 802.1Q, IEEE 802.3ah, IEEE 802.1ag
RAM
16 GB
Built-in Devices
32 GB eUSB
Miscellaneous
MTBF
146,700 hours
Compliant Standards
EN 61000-3-2, EN55022, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-3, EN55024, CISPR 22, EN50082-1, EN 61000-6-1, AS/NZS 60950-1, ICES-003 Class A, UL 60950-1, IEC 60950-1, EN 60950-1, GB 4943, GR-1089-CORE, VCCI Class A, GR-63-CORE, FCC CFR47 Part 15 A, CNS 13438 Class A, EN 300 386, KN35, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, AS/NZS CISPR 32 Class A, KN32 Class A, IEC/EN 61000-4-11, IEC/EN 61000-4-2, EN 55032 Class A, EN 55032, CISPR 32 Class A, CAN/CSA-C22.2 No. 60950-1, EN 55035
