Networking
Ports
Gigabit Ethernet x 8
Connectivity Technology
Wired
Cabling Type
Ethernet 1000Base-X
Data Link Protocol
Gigabit Ethernet
Capacity
IGMP groups: 1000 ¦ VLAN IDs: 256 ¦ Spanning Tree Protocol instances: 128 ¦ ACL: 1500
MAC Address Table Size
8000 entries
Network / Transport Protocol
TCP/IP, UDP/IP, NTP, ARP, FTP, BOOTP, DHCP, HTTP
Remote Management Protocol
SNMP 1, SNMP 2, SNMP, RMON, Telnet, SNMP 3, HTTP, TFTP, SSH, SCP, NETCONF, RESTCONF, NTP, ICMP, DHCP, RSTP, YANG, TACACS+, RADIUS
Features
IGMP snooping, DiffServ support, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, STP support, MSTP support, DHCP snooping, QoS, DHCP server, PVST+, UDLD, LACP support, LLDP support, DHCP relay, Port Security, RSPAN, MIB, dynamic ARP protection, static routing, FNF, PTP, IGMP filtering, IP source guard, REP, SmartPort technology, IGMP querier, Voice VLAN, Guest VLAN, SPAN, VTP v.3, BPDU Guard, 802.1x filtering, VTP v.2, EtherChannel support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.3ah, IEEE 802.1ab (LLDP), IEEE 1588v2
Miscellaneous
MTBF
5,572,640 hours
Compliant Standards
CISPR 24, EN55024, EN 61000-6-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, ICES-003 Class A, EN 61000-4-5, EN 61000-6-2, EN 61000-4-8, IEC 60950-1, EN 61000-6-4, IEC 60068-2-30, IEC 60068-2-27, EN 61326-1, EN 61000-4-16, EN 61000-4-29, IEC 60068-2-14, IEC 60068-2-78, EN 50121-4, IP30, VCCI Class A, CISPR 11 class A, EN 61000-4-10, EN 61000-4-18, IEC 61850-3, FCC CFR47 Part 15 B Class A, CNS 13438 Class A, EN 300 386, KN35, UL/CSA60950-1, AS/NZS CISPR 32 Class A, KN32 Class A, IEC 62368-1, EN 55032, EN 60068-2-52, EN 60068-2-60, CISPR 32 Class A, UL 62368-1, EN 60079-15, CB 60950-1, IEC 60079-0, IEC 60079-15, EN 60079-0, EN 61000-4-17, CAN/CSA C22.2 No. 213, UL 121201, EN 61850-3, UL/CSA 61010-2-201, IEC/EN 61010-2-201, UL/CSA 60079-0, UL/CSA 60079-15, CSA 62368-1, CB 62368-1
