Name: Ciena Service Delivery Switch 3903x - Switch - Managed - 2 x Gigabit SFP + 1 x combo Gigabit Ethernet/Gigabit SFP - desktop, wall-mountable - AC 100 - 240 V
Brand: CIENA
SKU: 1TACCRAC-021950
Price: 270.1 GBP
Availability: OutOfStock

Overview

Main features

Ciena Service Delivery Switch 3903x
Switch
Managed
2 x Gigabit SFP + 1 x combo Gigabit Ethernet/Gigabit SFP
desktop, wall-mountable
AC 100
240 V

Overview

Ciena's 3903x Service Delivery Switch is an advanced Ethernet business demarcation device in a cost-effective and compact form factor.

Specification

Product Description Ciena Service Delivery Switch 3903x - switch - Managed

Device Type Switch - Managed

Subtype Gigabit Ethernet

Ports 2 x Gigabit SFP + 1 x combo Gigabit Ethernet/Gigabit SFP

MAC Address Table Size 16000 entries

Jumbo Frame Support 9216 bytes

Routing Protocol IGMPv2, IGMP, IGMPv3, Two-Way Active Measurement Protocol (TWAMP), MSTP, RSTP

Remote Management Protocol SNMP 1, RMON 2, RMON, Telnet, SNMP 3, SNMP 2c, TFTP, SSH-2, CLI, SFTP

Features IGMP snooping, DoS attack prevention, Broadcast Storm Control, Multicast Storm Control, Trivial File Transfer Protocol (TFTP) support, fanless, Link Aggregation Control Protocol (LACP), DHCP client, Multicast filtering function, DNS client, NTP client, Telnet server, Q-in-Q tunnelling, IPv4 and IPv6 dual stack, Virtual Link Loss Indication (VLLI), Remote Link Loss Forwarding (RLLF)

Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1x, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), ITU-T Y.1731, ITU-T G.8032, ITU-T Y.1564

Power AC 100 - 240 V (50/60 Hz)

Dimensions (WxDxH) 15.2 cm x 17.3 cm x 19.6 cm

Weight 740 g

General

Device Type Switch - Managed

Enclosure Type Desktop, wall-mountable

Subtype Gigabit Ethernet

Ports 2 x Gigabit SFP + 1 x combo Gigabit Ethernet/Gigabit SFP

MAC Address Table Size 16000 entries

Jumbo Frame Support 9216 bytes

Routing Protocol IGMPv2, IGMP, IGMPv3, Two-Way Active Measurement Protocol (TWAMP), MSTP, RSTP

Remote Management Protocol SNMP 1, RMON 2, RMON, Telnet, SNMP 3, SNMP 2c, TFTP, SSH-2, CLI, SFTP

Encryption Algorithm MD5

Authentication Method RADIUS, TACACS+

Features IGMP snooping, DoS attack prevention, Broadcast Storm Control, Multicast Storm Control, Trivial File Transfer Protocol (TFTP) support, fanless, Link Aggregation Control Protocol (LACP), DHCP client, Multicast filtering function, DNS client, NTP client, Telnet server, Q-in-Q tunnelling, IPv4 and IPv6 dual stack, Virtual Link Loss Indication (VLLI), Remote Link Loss Forwarding (RLLF)

Compliant Standards IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1x, IEEE 802.1ad, IEEE 802.3ah, IEEE 802.1ag, IEEE 802.1ab (LLDP), ITU-T Y.1731, ITU-T G.8032, ITU-T Y.1564

Status Indicators Power, status, alarm

Expansion / Connectivity

Interfaces 1 x 1000Base-T RJ-45 ¦ 3 x Gigabit LAN SFP ¦ 1 x console RJ-45

Power

Power Device External power adapter

Voltage Required AC 100 - 240 V (50/60 Hz)

Miscellaneous

Compliant Standards VCCI, CISPR 22 Class B, CISPR 24, EN55022, EN55024, ICES-003 Class B, IEC 60950-1, EN 60950-1, CAN/CSA C22.2 No. 60950-1-07, NRTL, VCCI Class B, RCM, EMC 2004/108/EC, LVD 2006/95/EC, WEEE 2002/96/EC, FCC Part 15 Class B, EN 300 386, RoHS 2 (2011/65/EU), UL/CSA60950-1 (2nd Edition)

Dimensions & Weight

Width 15.2 cm

Depth 17.3 cm

Height 19.6 cm

Weight 740 g

Environmental Parameters

Min Operating Temperature 0 °C

Max Operating Temperature 40 °C

Humidity Range Operating 5 - 90% (non-condensing)

Min Storage Temperature -40 °C

Max Storage Temperature 70 °C
