Name: 10-PORT DESKTOP GIGABIT POE SURVEILLANCE SWITCH 130W POE
Brand: D-LINK
SKU: 1TNETNHS-067688
Price: 195.14 GBP
Availability: OutOfStock

Overview

Main features

D-Link DSS 200G-10MP
Switch
Managed
8 x 10/100/1000 (PoE) + 2 x Gigabit SFP
rack-mountable
PoE (130 W)

Overview

The DSS-200G Series is a range of switches designed to meet the surveillance requirements of small, medium, and enterprise businesses.

Specification

Product Description D-Link DSS 200G-10MP - switch - 8 ports - Managed - rack-mountable

Device Type Switch - 8 ports - Managed

Enclosure Type Rack-mountable 1U

Subtype Gigabit Ethernet

Ports 8 x 10/100/1000 (PoE) + 2 x Gigabit SFP

Power Over Ethernet (PoE) PoE

PoE Budget 130 W

Performance Switching bandwidth: 20 Gbps ¦ Forwarding bandwidth: 14.88 Mbps

Capacity Packet buffer size: 4.1 Mbit ¦ Virtual interfaces (VLANs): 4094 ¦ VLAN groups: 128 ¦ QoS priority queues per port: 4

MAC Address Table Size 8000 entries

Jumbo Frame Support 10240 bytes

Routing Protocol IGMP, IGMPv2, STP, RSTP

Remote Management Protocol SNMP, SNMP 2, MIB, ICMP

Features 6KV Surge protection, fanless, ONVIF support, VLAN support, built-in DIP switch, QoS, isolate mode, PD-Alive, flow control, full duplex mode, half duplex mode, auto-uplink (auto MDI/MDI-X), auto-negotiation, port-based VLAN, Auto Surveillance VLAN, tagged VLAN, Voice VLAN, VLAN management, Asymmetric VLAN, HOL Blocking Prevention, IGMP snooping, ERPS, loopback detection, Cable Diagnostics Function, LLDP support, port mirroring, MLD snooping, WRR, Broadcast Storm Control, Multicast Storm Control, Unknown Storm Control, DoS attack prevention, Green Technology, EEE, UDP support, TCP support, ARP support, BOOTP support, DHCP client, reset button

Compliant Standards IEEE 802.3af, IEEE 802.3at, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.1Q, ITU-T G.8032, IEEE 802.1D, IEEE 802.1w, IEEE 802.1p

Power AC 100-240 V (50 - 60 Hz)

Dimensions (WxDxH) 28 cm x 18 cm x 4.4 cm

Weight 1.55 kg

Localisation Europe

General

Device Type Switch - 8 ports - Managed

Enclosure Type Rack-mountable 1U

Subtype Gigabit Ethernet

Ports 8 x 10/100/1000 (PoE) + 2 x Gigabit SFP

Power Over Ethernet (PoE) PoE

PoE Budget 130 W

Performance Switching bandwidth: 20 Gbps ¦ Forwarding bandwidth: 14.88 Mbps

Capacity Packet buffer size: 4.1 Mbit ¦ Virtual interfaces (VLANs): 4094 ¦ VLAN groups: 128 ¦ QoS priority queues per port: 4

MAC Address Table Size 8000 entries

Jumbo Frame Support 10240 bytes

Routing Protocol IGMP, IGMPv2, STP, RSTP

Remote Management Protocol SNMP, SNMP 2, MIB, ICMP

Encryption Algorithm SSL

Features 6KV Surge protection, fanless, ONVIF support, VLAN support, built-in DIP switch, QoS, isolate mode, PD-Alive, flow control, full duplex mode, half duplex mode, auto-uplink (auto MDI/MDI-X), auto-negotiation, port-based VLAN, Auto Surveillance VLAN, tagged VLAN, Voice VLAN, VLAN management, Asymmetric VLAN, HOL Blocking Prevention, IGMP snooping, ERPS, loopback detection, Cable Diagnostics Function, LLDP support, port mirroring, MLD snooping, WRR, Broadcast Storm Control, Multicast Storm Control, Unknown Storm Control, DoS attack prevention, Green Technology, EEE, UDP support, TCP support, ARP support, BOOTP support, DHCP client, reset button

Compliant Standards IEEE 802.3af, IEEE 802.3at, IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.3az, IEEE 802.1Q, ITU-T G.8032, IEEE 802.1D, IEEE 802.1w, IEEE 802.1p

RAM 128 MB DDR3 SDRAM

Flash Memory 32 MB

Status Indicators Alarm, PoE, power, link/activity/speed

Expansion / Connectivity

Interfaces 8 x 10/100/1000 Base-T RJ-45 PoE - 90 W ¦ 2 x 1000Base-T SFP ¦ 1 x alarm input RJ-45

Power

Power Device Internal power supply

Voltage Required AC 100-240 V (50 - 60 Hz)

Power Consumption Stand by 10.4 Watt

Miscellaneous

Included Accessories Rack mounting brackets

Rack Mounting Kit Included

MTBF 345,045 hours

Compliant Standards FCC, IC, BSMI, cUL, UL, LVD, CB

Localisation Europe

Dimensions & Weight

Width 28 cm

Depth 18 cm

Height 4.4 cm

Weight 1.55 kg

Environmental Parameters

Min Operating Temperature -5 °C

Max Operating Temperature 50 °C

Humidity Range Operating 0 - 95% (non-condensing)

Min Storage Temperature -40 °C

Max Storage Temperature 70 °C

Humidity Range Storage 0 - 95% (non-condensing)
