Barcode
Interface Type
USB
Minimum Bar Width
3 mil
Scan Field Width
3 cm - 60 cm
Scan Element Type
Visible laser diode
Sensor Resolution
1280 x 960
Light Source Wave Length
650 nm
Scan Mode
Fixed projection
Skew (Degrees)
60
Pitch (Degrees)
60
Print Contrast Signal (PCS)
25%
Decode Capability
EAN/JAN, UPC, Australian Post, Aztec code, BC 412, British Post, CC-A, CC-B, CC-C, China Han Xin Code, China Post, Codabar, Code 11, Code 128, Code 2 of 5, Code 39, Code 93, Data Matrix, Datalogic 2 of 5, EAN-128, GS1 DataBar Composites, GS1 DataBar Expanded, GS1 DataBar Expanded Stacked, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, IATA, Industrial 2 of 5, Intelligent Mail Barcode, Interleaved 2 of 5, Japanese Post, Kix (Netherlands) Post, Korea Post, MacroPDF417, Matrix 2 of 5, MaxiCode, Micro QR code, MicroPDF417, MSI-Plessey, PDF417, Pharmacode 39, PLANET, Postnet, QR code, Royal Mail, RSS-14, Standard 2 of 5, Telepen, Trioptic Code, UPC/EAN/JAN Composites, UPC-A / E
TTL Decoding
Decoded
Connectivity Technology
Wired
OK Notification
Beeper, LED indicator
Features
White LEDs illumination, Green Spot technology, image capturing, maximum resolution down to 2 mils
