Barcode
Interface Type
Keyboard wedge, RS-232, USB
Scan Element Type
2D imager
Sensor Resolution
1280 x 800
Light Source Wave Length
650 nm
Skew (Degrees)
65
Pitch (Degrees)
65
Print Contrast Signal (PCS)
15%
Decode Capability
GS1 DataBar Composites, Aztec code, China Han Xin Code, Data Matrix, MaxiCode, Micro QR code, Australian Post, British Post, China Post, Japanese Post, Kix (Netherlands) Post, PLANET, Postnet, Royal Mail, RM4SCC, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MacroPDF417, MicroPDF417, PDF417, UPC A Composite, UPC E Composite
TTL Decoding
Decoded
Connectivity Technology
Wired
OK Notification
Beeper, LED indicator
Features
Green Spot technology, Datalogic Three Green Lights (3GL), Direct Part Mark (DPM), Digimarc Barcode Technology
