Barcode
Interface Type
Bluetooth 4.0
Minimum Bar Width
3 mil
Scan Element Type
2D imager - LED
Sensor Resolution
1280 x 960
Light Source Wave Length
617 nm
Scan Mode
Single-pass
Max Working Distance
93.5 cm
Skew (Degrees)
60
Pitch (Degrees)
60
Print Contrast Signal (PCS)
16%
Decode Capability
EAN/JAN, Code 93, Code 39, ISBT 128, NW-7, GS1 DataBar, QR code, MaxiCode, Aztec code, Bookland, Code 39 Full ASCII, MicroPDF417, Italy Pharmacode, Codabar, Code 128, Code 11, UPC, PDF417, MSI-Plessey, Data Matrix, TLC39, Australian Post, Canadian Post, Japanese Post, Kix (Netherlands) Post, ISSN, UK Post, Micro QR code, 4-State postal code, China Han Xin Code, UPU FICS, DotCode, US Planet, US Postnet, USPS 4-state (US4CB), Korean 3 of 5, Base 32, Chinese Sensible Code
TTL Decoding
Decoded
Connectivity Technology
Wireless
OK Notification
Beeper, LED indicator
Features
PRZM Intelligent Imaging technology, Digimarc Barcode Technology, 15 kV ESD protection (air discharge), 8 kV ESD protection (direct discharge), 8 kV ESD protection (indirect discharge)
Miscellaneous
Included Accessories
Cradle
Compliant Standards
EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class B, RoHS, FIPS 140-2, UL 60950-1, IP52, CAN/CSA C22.2 No. 60950-1-07, EN 50581, IEC 62471, FCC CFR47 Part 15 B Class B, EN 55032 Class B, ICES-003 issue 6 Class B, EN60950-1 (2nd Edition) + A11 + A1 + A12 + A2:2013, EN60950-1 (2nd Edition) + A1 + A2, EN 60601-1-2:2015
