Power Output Connectors Details6 x power IEC 60320 C13 10A
Output VoltageAC 200/208/220/230/240 V 50/60 Hz
Power Capacity900 Watt / 1000 VA
Output WaveformSinewave
Efficiency89%, 94% Eco mode
Power Factor (PF)0.9
Battery
TechnologyLead Acid
Capacity9 Ah
Run Time (Up To)14 min at 500 Watts ¦ 7 min at 800 Watts ¦ 24 min at 300 Watts ¦ 6 min at 900 Watts
FeaturesSealed
Networking
Remote Management InterfaceRS-232, USB
Expansion / Connectivity
Interfaces1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x management (USB) - 4 pin USB Type B ¦ EPO (emergency power off) - mini terminal block ¦ Relay output - mini terminal block
Expansion Slots1 (total) / 1 (free) x Expansion Slot
Miscellaneous
Cables Included2 x power cable (IEC) - external ¦ Serial cable - external ¦ USB cable - external ¦ AC input cable (BS 1363) - external
FeaturesAdvance Battery Management (ABM), LCD display, deep discharge protection, automatic self-test, temperature-compensated battery charging, 3-stage charging, double conversion, power measuring
Compliant StandardsUL 1778, IEC 62040-2, cULus, EN 62040-2, EAC, IEC 62040-1, EN 62040-1, DNV-GL
