General
Device Type
Network surveillance camera (no lens)
Form Factor
Dome
Connectivity Technology
Wired
Width
25.3 cm
Depth
25.3 cm
Height
13 cm
Weight
3 kg
Camera
Type
Colour - Day&Night - fixed - outdoor - vandal-proof
Digital Video Format
MJPEG, H.264, H.265
Motion Detection
Yes
Exposure Range
2 sec - 1/12000 sec
RAM
3 GB
Flash Memory
768 MB
Features
Backlight Compensation (BLC), image flip, image mirror, Wide Dynamic Range (WDR), face detection, Privacy Mask Function, Samsung Super Dynamic Range (SSDR), Highlight Compensation (HLC), Digital Image Stabilization (DIS), Lens Distortion Compensation (LDC), Camera Tampering Detection, Variable Bitrate (VBR), Constant Bitrate (CBR), Multicast Streaming, Defog, auto gain control, auto white balance, Defocus Detection, ONVIF (Profile S) support, loitering detection, entrance / exit detection, appearing / disappearing detection, digest authentication, Samsung Super Noise Reduction (SSNRV), WiseStream II support, IP address filtering, fog detection, Unicast Streaming, aluminium housing, ONVIF (Profile T) support, built-in 4 head multi-directional camera (no lens modules), Virtual Line detection, Directional Detection
Interfaces
Video
Composite video
Network Interface
Ethernet 10Base-T/100Base-TX
Network Protocols
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, IGMP, SSL, QOS, SRTP, EAP, PIM-SM, LLDP
Expansion / Connectivity
Ports
Composite video ¦ LAN/power - RJ-45
Supported Memory Cards
microSD Card, microSDHC Card, microSDXC Card
Miscellaneous
Compliant Standards
FCC, cULus, IK10, IP66, EAC, IEEE 802.3at, IEEE 802.1x
Colour
White, RAL 9003
Power
Power Requirements
PoE Plus Class 4
Power Device
25.5 Watt
Environmental Parameters
Min Operating Temperature
-40 °C
Max Operating Temperature
55 °C
Relative Humidity (operating)
0 - 90% RH
