General
Device Type
Network surveillance camera
Audio Support
Yes
Audio Formats
G.726, ADPCM, AAC-LC, G.711, U-LAW
Form Factor
Dome
Camera Mount Type
Ceiling mount
Connectivity Technology
Wired
Width
25.1 cm
Depth
25.1 cm
Height
11.65 cm
Weight
3 kg
Camera
Type
Colour - Day&Night - pan / tilt / zoom - outdoor, indoor
Digital Video Format
MJPEG, H.264, H.265
Max Digital Video Resolution
1920 x 1080
Motion Detection
Yes
Exposure Range
2 sec - 1/12000 sec
Minimum Illumination
0.04 lux - colour - F2.2 - shutter 1/30 sec ¦ 0.004 lux - B&W - F2.2 - shutter 1/30 sec
Digital Video Capture Resolution
1280 x 720, 720 x 480, 640 x 480, 1280 x 960, 320 x 240, 1024 x 768, 720 x 576, 1280 x 1024, 1920 x 1080, 640 x 360, 800 x 448
Frame Rate (max)
60 frames per second
RAM
5 GB
Features
Backlight Compensation (BLC), digital noise reduction, image flip, image mirror, Wide Dynamic Range (WDR), face detection, Motion Detection Technology, Privacy Mask Function, Samsung Super Dynamic Range (SSDR), Highlight Compensation (HLC), Digital Image Stabilization (DIS), Lens Distortion Compensation (LDC), tamper-detection, notification picture to E-mail, notification picture to FTP, Audio Detection, Multicast Streaming, Defog, auto gain control, auto white balance, Defocus Detection, ONVIF (Profile S) support, entrance / exit detection, appearing / disappearing detection, digest authentication, WiseStream II support, anti-flicker, IP address filtering, Hallway View, fog detection, motion detection, Unicast Streaming, Handover, ONVIF (Profile T) support, direction detection, Virtual Line detection, user access log, auto ICR, trigger recording
Lens Construction
Type
Motorized zoom
Optical Zoom
2 x
Focal Length
3 mm - 6 mm
Lens Iris
F/2.2-3.1 fixed iris
Focus Adjustment
Automatic
Min Focus Distance
0.5 m
Horizontal Field of View (degree)
56.3 - 107
Vertical Field of View (degree)
31.5 - 57
Diagonal Field of View (degree)
64.3 - 126
