General
Device Type
Network surveillance camera
Audio Support
Yes
Audio Formats
G.726, ADPCM, G.711, U-LAW
Connectivity Technology
Wired
Width
7 cm
Depth
7 cm
Height
24.6 cm
Weight
700 g
Camera
Type
Colour - Day&Night - fixed - outdoor - dustproof / waterproof
Digital Video Format
MJPEG, H.264, H.265
Max Digital Video Resolution
1920 x 1080
Motion Detection
Yes
Exposure Range
1/5 sec - 1/12000 sec
Minimum Illumination
0.1 lux - colour - F2.0 - shutter 1/30 sec ¦ 0 lux - B&W - infrared LEDs on
Infrared LEDs
Yes
Infrared Distance
20 m
Video Capture
1920 x 1080 @ 30 fps
RAM
512 MB
Flash Memory
256 MB
Features
Backlight Compensation (BLC), image flip, image mirror, Wide Dynamic Range (WDR), Motion Detection Technology, infrared cut filter, Privacy Mask Function, Samsung Super Dynamic Range (SSDR), Lens Distortion Compensation (LDC), tamper-detection, Variable Bitrate (VBR), Constant Bitrate (CBR), Multicast Streaming, Smart Codec, auto white balance, Defocus Detection, ONVIF (Profile S) support, ONVIF (Profile G) support, Samsung Super Noise Reduction (SSNR), WiseStream II support, anti-flicker, IP address filtering, Hallway View, Unicast Streaming, Handover, ONVIF (Profile T) support, Virtual Line detection
Image Sensor
Type
2 MP CMOS 1/2.8"
Effective Pixels
1920 x 1080
Lens Construction
Type
Fixed focal
Focal Length
2.8 mm
Lens Iris
F/2.0
Horizontal Field of View (degree)
113.74
Vertical Field of View (degree)
61.5
Diagonal Field of View (degree)
134.45
Interfaces
Video
Composite video
Network Interface
Ethernet 10Base-T/100Base-TX
Network Protocols
DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, IGMP, SSL, QOS, EAP, LLDP
Alarm Inputs Qty
1
Alarm Outputs Qty
1
Expansion / Connectivity
Ports
Composite video ¦ Audio line-in/microphone ¦ LAN/power - RJ-45
Supported Memory Cards
microSD Card, microSDHC Card, microSDXC Card
Miscellaneous
Compliant Standards
IK10, IP66, IEEE 802.3af, IEEE 802.1x
Colour
Dark grey
Power
Power Requirements
DC 12 V / PoE Class 3
Power Device
7 Watt
Software / System Requirements
OS Required
Microsoft Windows 7, Windows 8.1, Windows 10, Apple macOS 10.12, Apple macOS 10.13, Apple macOS 10.14
Environmental Parameters
Min Operating Temperature
-30 °C
Max Operating Temperature
55 °C
Relative Humidity (operating)
0 - 90%
